CTMMP2712F-R68M

Fixed Inductors Overview

The CTMMP2712F-R68M is a fixed shielded power inductor manufactured by Central Technologies. It features a nominal inductance of 0.68 µH with a tolerance of ±20%. The component has a maximum DC resistance of 5.5 mΩ and supports a current rating of 22 A. Designed for surface mount applications, it utilizes a rectangular package with radial terminal positioning.

Fixed Inductors Feature Summary

• Shielded construction to minimize electromagnetic interference
• High current handling capability for power circuits
• Low DC resistance for improved efficiency

Fixed Inductors Applications

• Power supply filtering
• DC-DC converter input/output stages
• General purpose power inducting

Fixed Inductors Procurement Notes

Verify the specific manufacturer datasheet for precise electrical characteristics and mechanical dimensions before integration. Confirm that the surface mount package type aligns with the target PCB footprint and soldering process requirements. Ensure the operating temperature range meets the environmental conditions of the final assembly.

Fixed Inductors Selection Notes

Select this component when high current capacity and low impedance are required in a compact surface mount form factor. The shielded design makes it suitable for noise-sensitive environments. Compare the 22 A rating against peak load currents to ensure adequate margin. Evaluate the 0.68 µH value against circuit switching frequency requirements.

Fixed Inductors Part Context

This part belongs to the CTMMP2712F series of fixed inductors from Central Technologies. The series includes various inductance values such as 4.7 µH and 8.2 µH within the same physical package family. These components are designed for general-purpose power electronics applications requiring robust performance.

Fixed Inductors Replacement Considerations

Cross-reference with other SMD shielded power inductors offering similar 0.68 µH inductance and comparable current ratings. Verify pin compatibility and thermal performance if substituting with parts from different manufacturers.
