CTMMP2906F-1R0M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is SMD Shielded Power Inductor. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for CTMMP2906F-1R0M
- Description：SMD Shielded Power Inductor
- Series：-
- Mfr：Central Technologies
- Package：Bulk
- Type：-
- Material - Core：-
- Inductance：1 µH
- Tolerance：±20%
- Current Rating (Amps)：10:00 AM
- Current - Saturation (Isat)：-
- Shielding：Shielded
- DC Resistance (DCR)：17mOhm
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-55°C ~ 125°C
- Inductance Frequency - Test：-
- Mounting Type：Surface Mount
- Package / Case：-
- Supplier Device Package：-
- Size / Dimension：0.260" L x 0.287" W (6.60mm x 7.30mm)
- Height - Seated (Max)：0.063" (1.60mm)
- Features：-
Fixed Inductors datasheet and documents for CTMMP2906F-1R0M
Fixed Inductors Overview
The CTMMP2906F-1R0M is a shielded power inductor from Central Technologies, featuring a metal molded construction and surface mount design. It provides an inductance of 1 µH with a tolerance of ±20%. The component has a maximum DC resistance of 17 mΩ and supports a current rating of 10 A. Operating temperature range spans from -55°C to +125°C. Physical dimensions are 0.260" L x 0.287" W (6.60mm x 7.30mm) with a seated height of 0.063" (1.60mm).
Fixed Inductors Feature Summary
- Shielded metal molded construction for electromagnetic interference reduction.
- Surface mount mounting type suitable for automated assembly.
- Wide operating temperature range supporting harsh environments.
Fixed Inductors Applications
- Power supply filtering circuits
- DC-DC converter energy storage
- General purpose power inductor applications
Fixed Inductors Procurement Notes
Verify the specific part number suffix against official Central Technologies documentation to ensure correct inductance value and tolerance specifications. Confirm that the required current ratings align with the system's thermal and electrical constraints before procurement. Ensure compatibility with surface mount reflow soldering profiles.
Fixed Inductors Selection Notes
Select this component based on its 1 µH inductance requirement and 10 A current handling capability. Consider the physical footprint of 6.60mm x 7.30mm for PCB layout constraints. Evaluate the 17 mΩ DC resistance impact on efficiency. Verify that the shielded design meets the electromagnetic compatibility requirements of the target application.
Fixed Inductors Part Context
This component belongs to the CTMMP series of fixed inductors manufactured by Central Technologies. The series offers various inductance values within the same package outline, allowing for design flexibility while maintaining consistent mechanical integration. The metal mold construction distinguishes it from other core types in the manufacturer's portfolio.
Fixed Inductors Replacement Considerations
Cross-reference with CTMMP2906F-R47M or CTMMP2906F-3R3M if different inductance values are acceptable within the same package and performance envelope. Verify that substitute parts maintain identical shielding characteristics and current ratings to ensure circuit stability.
