CTMMP2912F-4R7M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is SMD Shielded Power Inductor. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for CTMMP2912F-4R7M
- Description：SMD Shielded Power Inductor
- Series：-
- Mfr：Central Technologies
- Package：Bulk
- Type：-
- Material - Core：-
- Inductance：4.7 µH
- Tolerance：±20%
- Current Rating (Amps)：6.5 A
- Current - Saturation (Isat)：-
- Shielding：Shielded
- DC Resistance (DCR)：33mOhm
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-55°C ~ 125°C
- Inductance Frequency - Test：-
- Mounting Type：Surface Mount
- Package / Case：-
- Supplier Device Package：-
- Size / Dimension：0.260" L x 0.287" W (6.60mm x 7.30mm)
- Height - Seated (Max)：0.118" (3.00mm)
- Features：-
Fixed Inductors datasheet and documents for CTMMP2912F-4R7M
Fixed Inductors Overview
The CTMMP2912F-4R7M is a shielded power inductor manufactured by Central Technologies. It features a nominal inductance of 4.7 µH with a tolerance of ±20%. The component has a maximum rated current of 6.5 A and a DC resistance of 33 mΩ. It utilizes a surface-mount technology (SMT) package with dimensions of 29x12 mm.
Fixed Inductors Feature Summary
- Shielded construction to minimize electromagnetic interference
- High current handling capability for power applications
- Low DC resistance for improved efficiency
Fixed Inductors Applications
- Power supply circuits
- DC-DC converters
- General purpose power filtering
Fixed Inductors Procurement Notes
Verify the exact part number CTMMP2912F-4R7M against official Central Technologies documentation to confirm specifications. Ensure compatibility with your design requirements regarding current ratings and physical dimensions before procurement.
Fixed Inductors Selection Notes
Select this component when a shielded power inductor with high current capacity is required. Consider the 29x12 mm footprint and 4.7 µH inductance value relative to your circuit's energy storage needs and space constraints.
Fixed Inductors Part Context
This inductor belongs to the CTMMP series, designed for robust power electronics applications. It offers a balance of high current handling and low resistance, suitable for demanding power conversion environments.
Fixed Inductors Replacement Considerations
Check for direct substitutes within the CTMMP series or other shielded power inductors with matching 4.7 µH inductance and similar current ratings. Verify pinout and dimensional compatibility.
