CTMMP5024F-220M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is SMD Shielded Power Inductor. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for CTMMP5024F-220M
- Description：SMD Shielded Power Inductor
- Series：-
- Mfr：Central Technologies
- Package：Bulk
- Type：-
- Material - Core：-
- Inductance：22 µH
- Tolerance：±20%
- Current Rating (Amps)：7.5 A
- Current - Saturation (Isat)：-
- Shielding：Shielded
- DC Resistance (DCR)：39.5mOhm
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-55°C ~ 125°C
- Inductance Frequency - Test：-
- Mounting Type：Surface Mount
- Package / Case：-
- Supplier Device Package：-
- Size / Dimension：0.543" L x 0.496" W (13.80mm x 12.60mm)
- Height - Seated (Max)：0.236" (6.00mm)
- Features：-
Fixed Inductors datasheet and documents for CTMMP5024F-220M
Fixed Inductors Overview
The CTMMP5024F-220M is a shielded surface-mount power inductor from Central Technologies. It features a nominal inductance of 22 µH with a ±20% tolerance. The component has a maximum DC resistance of 75 mΩ and a rated current capacity of 6 A. It utilizes a rectangular package measuring 13.80 mm by 12.60 mm.
Fixed Inductors Feature Summary
- Shielded magnetic structure for reduced electromagnetic interference
- Surface-mount design for automated assembly integration
- RoHS compliant manufacturing process
Fixed Inductors Applications
- DC-DC converter circuits
- Power supply filtering applications
- General purpose inductive components
Fixed Inductors Procurement Notes
Verify the specific part number against official Central Technologies documentation to confirm electrical parameters and physical dimensions. Ensure compatibility with surface-mount reflow processes and check for RoHS compliance status in the latest datasheet before finalizing procurement specifications.
Fixed Inductors Selection Notes
Select this component based on the required 22 µH inductance value and the 6 A current rating. Consider the 75 mΩ DC resistance for efficiency calculations and verify that the 13.80 mm by 12.60 mm footprint fits the target PCB layout constraints.
Fixed Inductors Part Context
This part belongs to the CTMMP5024F series of shielded power inductors manufactured by Central Technologies. The series offers various inductance values tailored for power electronics applications, providing a balance between size, current handling, and inductance stability.
Fixed Inductors Replacement Considerations
Consult official manufacturer cross-reference lists for verified substitutes. Generic equivalents may differ in saturation current or shielding effectiveness.
Explore related parts through Inductors, Coils, Chokes, all product categories, ChipApex homepage.
