CTMMP6826AF-8R2M

Fixed Inductors Overview

The CTMMP6826AF-8R2M is a fixed shielded power inductor from Central Technologies. It features an inductance of 8.2 µH with ±20% tolerance. The component supports a maximum RMS current (Irms) of 25 A and a saturation current (Isat) of 31 A. Its direct current resistance (DCR) is 9.6 mΩ. The part utilizes surface mount technology for integration into electronic circuits.

Fixed Inductors Feature Summary

• Shielded magnetic structure to minimize electromagnetic interference
• High current handling capability suitable for power supply applications
• Low DC resistance for improved efficiency

Fixed Inductors Applications

• Point-of-load voltage regulation modules
• DC-DC converter output filtering
• Power distribution networks

Fixed Inductors Procurement Notes

Verify the specific suffix code against the manufacturer datasheet to confirm electrical parameters, as variations may exist within the series. Ensure the ordering documentation explicitly references the 8.2 µH value and the associated current ratings to prevent substitution errors with similar inductance values in the same package.

Fixed Inductors Selection Notes

Select this component when high current capacity is required alongside compact surface mount packaging. The 8.2 µH value and 25 A Irms rating make it suitable for high-power density designs. Consider thermal management requirements due to the significant current handling capabilities inherent to this series.

Fixed Inductors Part Context

This part belongs to the CTMMP6826AF series of shielded power inductors. The series offers various inductance values ranging from low microhenries to higher ranges, all sharing similar physical dimensions and mounting characteristics. The 'M' suffix denotes a standard ±20% inductance tolerance.

Fixed Inductors Replacement Considerations

Direct substitutes include other CTMMP6826AF variants with identical footprint but different inductance values if circuit design allows. Cross-brand replacements must match the 8.2 µH nominal value, 25 A minimum Irms, and 9.6 mΩ maximum DCR specifications.
