CTMMP73VCZF-R33M

$0.51

Description：SMD Shielded Power Inductor
Series：-
Mfr：Central Technologies
Package：Bulk

SKU:42da4a89e26e Category: Fixed Inductors Brand: Central Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

CTMMP73VCZF-R33M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is SMD Shielded Power Inductor. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for CTMMP73VCZF-R33M

Description：SMD Shielded Power Inductor
Series：-
Mfr：Central Technologies
Package：Bulk
Type：-
Material - Core：-
Inductance：0.33 µH
Tolerance：±20%
Current Rating (Amps)：33 A
Current - Saturation (Isat)：-
Shielding：Shielded
DC Resistance (DCR)：4mOhm
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-55°C ~ 125°C
Inductance Frequency - Test：-
Mounting Type：Surface Mount
Package / Case：-
Supplier Device Package：-
Size / Dimension：0.260" L x 0.287" W (6.60mm x 7.30mm)
Height - Seated (Max)：0.118" (3.00mm)
Features：-

Fixed Inductors datasheet and documents for CTMMP73VCZF-R33M

CTMMP73VCZF-R33M

Fixed Inductors Overview

The CTMMP73VCZF-R33M is a shielded surface-mount power inductor from Central Technologies. It features a nominal inductance of 0.33 µH with a tolerance of ±20%. The component has a maximum DC resistance of 4 mΩ and a current rating of 33 A. It operates within a temperature range of -55°C to +125°C.

Fixed Inductors Feature Summary

Shielded construction minimizes electromagnetic interference
Metal mold design for structural integrity
High current handling capability suitable for power applications

Fixed Inductors Applications

Power supply circuits
DC-DC converter modules
General purpose power inductor applications

Fixed Inductors Procurement Notes

Verify the specific part number CTMMP73VCZF-R33M against official Central Technologies documentation to confirm electrical parameters and physical dimensions. Ensure that the RoHS compliance status matches project requirements by checking the manufacturer's latest datasheet or certification documents before finalizing procurement decisions.

Fixed Inductors Selection Notes

Select this component when high current capacity and low DC resistance are required in a compact surface-mount form factor. The shielded design is appropriate for environments sensitive to magnetic field leakage. Confirm that the operating temperature range and inductance value align with the specific circuit design constraints.

Fixed Inductors Part Context

This component belongs to the CTMMP series of shielded power inductors manufactured by Central Technologies. The series is designed for surface-mount technology applications requiring robust performance in power conversion systems. The specific model indicates a 0.33 µH inductance value within this product line.
