CTMPC100805F-2R2M

$0.53

Description：2.2UH SMD SHLDED POWER INDUCTOR
Series：CTMPC100805F
Mfr：Central Technologies
Package：Tape & Reel (TR)

SKU:f78be56fb666 Category: Fixed Inductors Brand: Central Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

CTMPC100805F-2R2M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is 2.2UH SMD SHLDED POWER INDUCTOR. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for CTMPC100805F-2R2M

Description：2.2UH SMD SHLDED POWER INDUCTOR
Series：CTMPC100805F
Mfr：Central Technologies
Package：Tape & Reel (TR)
Type：Molded
Material - Core：-
Inductance：2.2 µH
Tolerance：±20%
Current Rating (Amps)：2:00 AM
Current - Saturation (Isat)：3.3A
Shielding：Shielded
DC Resistance (DCR)：115mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：2 MHz
Mounting Type：Surface Mount
Package / Case：1008 (2520 Metric)
Supplier Device Package：1008
Size / Dimension：0.098" L x 0.079" W (2.50mm x 2.00mm)
Height - Seated (Max)：0.047" (1.20mm)
Features：-

Fixed Inductors datasheet and documents for CTMPC100805F-2R2M

CTMPC100805F-2R2M

Fixed Inductors Overview

The CTMPC100805F-2R2M is a shielded molded inductor from Central Technologies, designed for surface-mount applications. It features an inductance of 2.2 µH with a tolerance of 20%. The component operates within a temperature range of -40°C to +125°C and utilizes a metal mold construction. This fixed inductor is housed in a 1008 (2520 Metric) package, providing a compact solution for power supply circuits requiring reliable magnetic shielding.

Fixed Inductors Feature Summary

Shielded molded construction for reduced electromagnetic interference
Wide operating temperature range suitable for harsh environments
Surface-mount design for automated assembly processes

Fixed Inductors Applications

DC-DC converter input and output filtering
Power supply circuit energy storage
Signal processing choke applications

Fixed Inductors Procurement Notes

Verify the specific manufacturer datasheet for detailed electrical characteristics and mechanical dimensions before integration. Confirm that the 1008 package footprint matches the target PCB layout requirements. Ensure the selected component meets the thermal management specifications for the intended operating environment. Cross-reference part numbers to avoid confusion with similar series variants.

Fixed Inductors Selection Notes

Choose this component when a compact shielded inductor is required for high-current applications. The 2.2 µH value suits moderate frequency switching regulators. Consider the saturation current limits relative to peak load conditions. The metal mold type offers durability compared to standard plastic packages. Evaluate space constraints against the 1008 package size.

Fixed Inductors Part Context

This part belongs to the CTMPC100805F series of fixed inductors manufactured by Central Technologies. The series includes various inductance values tailored for different power levels. The CTMPC designation indicates a shielded molded type, distinguishing it from unshielded or multilayer alternatives within the same brand portfolio.
