CTMPH060303F-R24M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is 0.24UH SMD MOLDED SHLD INDUCTOR. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for CTMPH060303F-R24M
- Description：0.24UH SMD MOLDED SHLD INDUCTOR
- Series：CTMPH060303F
- Mfr：Central Technologies
- Package：Tape & Reel (TR)
- Type：Molded
- Material - Core：-
- Inductance：240 nH
- Tolerance：±20%
- Current Rating (Amps)：2.6 mA
- Current - Saturation (Isat)：3.2A
- Shielding：Shielded
- DC Resistance (DCR)：54Ohm Max
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-40°C ~ 125°C
- Inductance Frequency - Test：2 MHz
- Mounting Type：Surface Mount
- Package / Case：0603 (1608 Metric)
- Supplier Device Package：603
- Size / Dimension：0.063" L x 0.031" W (1.60mm x 0.80mm)
- Height - Seated (Max)：0.031" (0.80mm)
- Features：-
Fixed Inductors datasheet and documents for CTMPH060303F-R24M
Fixed Inductors Overview
The CTMPH060303F-R24M is a shielded power inductor manufactured by Central Technologies. It features a surface-mount design with an inductance of 0.24 µH. The component utilizes a molded construction suitable for high-current applications. It is RoHS compliant and designed for general-purpose use in electronic circuits requiring compact magnetic components.
Fixed Inductors Feature Summary
- Shielded power inductor design to minimize electromagnetic interference
- Surface-mount technology for automated assembly integration
- RoHS compliant manufacturing process
Fixed Inductors Applications
- Power supply filtering
- DC-DC converter input/output stages
- General-purpose circuit protection
Fixed Inductors Procurement Notes
Verify the specific tolerance code and lead-free status against the manufacturer's current datasheet before ordering. Confirm that the package dimensions match the target PCB footprint requirements. Ensure the operating temperature range aligns with the intended application environment to guarantee long-term reliability and performance stability.
Fixed Inductors Selection Notes
Select this component when a low-profile, shielded inductor is required for space-constrained designs. The 0.24 µH value suits applications needing moderate energy storage with minimal magnetic leakage. Consider the series resistance and saturation current limits relative to the circuit load to ensure efficient operation without thermal issues.
Fixed Inductors Part Context
This part belongs to the CTMPH series of shielded power inductors from Central Technologies. The series offers various inductance values in standard surface-mount packages. These components are engineered for reliability in consumer electronics and industrial equipment where size and shielding are critical design factors.
Fixed Inductors Replacement Considerations
Direct substitutes include other 0.24 µH shielded SMD power inductors from Central Technologies such as the CTMPC080605F-R24M, provided the package size and electrical characteristics are compatible. Verify pinout and mechanical dimensions before swapping.
