CTP1330F-224K

Fixed Inductors Overview

The CTP1330F-224K is a general purpose fixed inductor manufactured by Central Technologies. It features a molded construction with an unshielded design and J-Lead surface mount terminals. The nominal inductance is 220 µH with a tolerance of ±10%. The component has a maximum DC resistance of 4.8 Ω and a maximum rated current of 0.179 A. It operates within a temperature range of -55 °C to 125 °C. The physical dimensions are 7.90 mm in length and 3.25 mm in width.

Fixed Inductors Feature Summary

• Molded unshielded construction for general purpose applications
• J-Lead surface mount termination style
• RoHS compliant manufacturing

Fixed Inductors Applications

• Power inductor circuits
• General electronic filtering
• Signal processing components

Fixed Inductors Procurement Notes

Verify the specific manufacturer datasheet for the CTP1330F-224K to confirm electrical tolerances and thermal ratings. Ensure the ordering suffix matches the required packaging configuration. Cross-reference the part number with official distributor catalogs to validate availability and authenticity before procurement.

Fixed Inductors Selection Notes

Select this component for applications requiring a 220 µH inductance value with moderate current handling capabilities. The J-Lead package facilitates automated surface mount assembly. Consider the 4.8 Ω DC resistance when designing low-loss power paths. Verify that the operating temperature range meets the environmental requirements of the target system.

Fixed Inductors Part Context

This inductor belongs to the CTP1330F series from Central Technologies, which offers various inductance values in a standardized rectangular SMD package. The series is designed for general purpose use in consumer and industrial electronics. Similar parts in the family include different inductance variants like the CTP1330F-334K and CTP1330F-184K.

Fixed Inductors Replacement Considerations

Direct substitutes may include other 220 µH SMD molded inductors with compatible current ratings and J-Lead terminations. Verify pin compatibility and physical footprint before substitution.
