CTPCI6045F-220M

Fixed Inductors Overview

The CTPCI6045F-220M is a shielded surface-mount power inductor manufactured by Central Technologies. It features a cylindrical package design with four dual-in-line terminals. The component has a nominal inductance of 22 µH and a maximum rated current of 2.4 A. Its DC resistance is specified at 0.088 Ω, with an inductance tolerance of 20%. The device operates at a test frequency of 2.52 MHz and is RoHS compliant.

Fixed Inductors Feature Summary

• Shielded construction for reduced electromagnetic interference
• Surface-mount technology for automated assembly
• Cylindrical package geometry

Fixed Inductors Applications

• DC-DC converter circuits

Fixed Inductors Procurement Notes

Verify the exact electrical parameters against the official Central Technologies datasheet before integration. Confirm that the surface-mount package dimensions and terminal configuration match the target PCB layout. Ensure the selected component meets the required thermal and current handling specifications for the specific application environment.

Fixed Inductors Selection Notes

Select this component based on its 22 µH inductance value and 2.4 A current rating suitability for the circuit design. Consider the shielded type to minimize magnetic field interference in dense layouts. Evaluate the surface-mount form factor for compatibility with manufacturing processes and space constraints within the electronic assembly.

Fixed Inductors Part Context

This part belongs to the CTPCI series of shielded power inductors from Central Technologies. The series includes variants such as the CTPCI7045F-221M, indicating a standardized product line focused on general-purpose inductive components for power management applications.

Fixed Inductors Replacement Considerations

Cross-reference with other Central Technologies shielded SMD inductors having similar 22 µH values and current ratings. Verify pinout and dimensional compatibility before substituting.
