CTRFB1010F-331K

$1.16

Description：330UH RADIAL FIXED INDUCTOR
Series：CTRFB1010F
Mfr：Central Technologies
Package：Bulk

SKU:9639ce9f3d1b Category: Fixed Inductors Brand: Central Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

CTRFB1010F-331K is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is 330UH RADIAL FIXED INDUCTOR. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for CTRFB1010F-331K

Description：330UH RADIAL FIXED INDUCTOR
Series：CTRFB1010F
Mfr：Central Technologies
Package：Bulk
Type：-
Material - Core：-
Inductance：330 µH
Tolerance：±10%
Current Rating (Amps)：1.4 A
Current - Saturation (Isat)：1.1A
Shielding：Unshielded
DC Resistance (DCR)：570mOhm Max
Q @ Freq：-
Frequency - Self Resonant：3.5MHz
Ratings：-
Operating Temperature：-40°C ~ 85°C
Inductance Frequency - Test：100 kHz
Mounting Type：Through Hole
Package / Case：Radial, Vertical Cylinder
Supplier Device Package：Radial
Size / Dimension：0.433" Dia (11.00mm)
Height - Seated (Max)：0.453" (11.50mm)
Features：-

Fixed Inductors datasheet and documents for CTRFB1010F-331K

CTRFB1010F-331K

Fixed Inductors Overview

CTRFB1010F-331K is a fixed radial inductor from Central Technologies with a nominal inductance of 330 µH and ±10% tolerance. It features a vertical cylinder package, unshielded construction, and a maximum DC resistance of 570 mΩ. The component supports a current rating of 1.4 A and complies with RoHS standards.

Fixed Inductors Feature Summary

Radial leaded vertical cylinder package
Unshielded magnetic design
RoHS compliant manufacturing

Fixed Inductors Applications

Peaking coils
General purpose filtering
DC-DC converter circuits

Fixed Inductors Procurement Notes

Verify the suffix 'F' confirms RoHS compliance status. Confirm the 1.4 A current rating and 570 mΩ DCR match circuit requirements. Ensure the unshielded configuration does not interfere with nearby components due to magnetic field exposure.

Fixed Inductors Selection Notes

Select this part for applications requiring a 330 µH inductance with high current handling. The unshielded design suits environments where magnetic interference is manageable. Verify that the radial vertical form factor fits the PCB layout constraints.

Fixed Inductors Part Context

This component belongs to the CTRFB1010F series of peaking coils. The series offers a wide range of inductance values from 12 µH to 18,000 µH. All parts in this series are available exclusively with ±10% tolerance.
