CTRL6050F-101M

Fixed Inductors Overview

The CTRL6050F-101M is a fixed wirewound power inductor manufactured by Central Technologies. It features an inductance of 100 µH and a maximum DC resistance of 350 mΩ. The component supports a current rating of 1.4 A and operates within a temperature range of -40°C to +85°C. It utilizes an unshielded design with nonstandard dimensions, measuring up to 0.331 inches (8.40 mm) in seated height.

Fixed Inductors Feature Summary

• Unshielded wirewound construction for general-purpose power applications
• High current handling capability rated at 1.4 A
• Wide operating temperature range from -40°C to +85°C

Fixed Inductors Applications

• Power supply filtering circuits
• General-purpose electronic equipment
• DC-DC converter input/output stages

Fixed Inductors Procurement Notes

Verify the specific tolerance code associated with the suffix 'M' against official datasheets, as it may indicate ±20% inductance tolerance depending on the manufacturer's marking convention. Confirm that the unshielded design meets electromagnetic interference requirements for the target application environment. Ensure the 1.4 A current rating aligns with peak load conditions to prevent saturation.

Fixed Inductors Selection Notes

Select this component when a 100 µH inductance value is required with a 1.4 A current capacity. The unshielded type is suitable where magnetic field containment is not critical or where cost efficiency is prioritized over EMI suppression. Verify footprint compatibility with PCB layout constraints given the nonstandard package dimensions.

Fixed Inductors Part Context

This part belongs to the CTRL6050F series of fixed inductors from Central Technologies. The series includes various inductance values and tolerance codes, such as the CTRL6050F-100M variant which offers 10 µH. The CTRL6050F designation indicates a specific form factor optimized for surface-mount or through-hole integration in power management modules.

Fixed Inductors Replacement Considerations

Direct substitutes include other 100 µH, 1.4 A unshielded wirewound inductors from Central Technologies with compatible mechanical footprints. Cross-manufacturer replacements must match the 350 mΩ DCR maximum and 1.4 A current rating to ensure circuit performance parity.
