CTSD10F-1R0M

$1.72

Description：1UH SMD SHLDED POWER INDUCTOR
Series：CTSD10F
Mfr：Central Technologies
Package：Tape & Reel (TR)

SKU:4a64206fe46f Category: Fixed Inductors Brand: Central Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

CTSD10F-1R0M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is 1UH SMD SHLDED POWER INDUCTOR. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for CTSD10F-1R0M

Description：1UH SMD SHLDED POWER INDUCTOR
Series：CTSD10F
Mfr：Central Technologies
Package：Tape & Reel (TR)
Type：-
Material - Core：-
Inductance：1 µH
Tolerance：±20%
Current Rating (Amps)：-
Current - Saturation (Isat)：2.25A
Shielding：Shielded
DC Resistance (DCR)：56mOhm
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 85°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.205" L x 0.205" W (5.20mm x 5.20mm)
Height - Seated (Max)：0.039" (1.00mm)
Features：-

Fixed Inductors datasheet and documents for CTSD10F-1R0M

CTSD10F-1R0M

Fixed Inductors Overview

The CTSD10F-1R0M is a shielded surface-mount power inductor manufactured by Central Technologies. It features a nominal inductance of 1 µH with a standard tolerance configuration. The component utilizes a rectangular package design suitable for automated assembly processes. Key electrical specifications include a maximum DC resistance of 20 mΩ and a rated DC current capacity of 3.7 A. The device is designed to operate within a temperature range of -30°C to +100°C, ensuring reliability in various electronic environments.

Fixed Inductors Feature Summary

Shielded construction minimizes electromagnetic interference coupling
Surface-mount technology enables efficient PCB integration
High current handling capability supports power supply applications

Fixed Inductors Applications

Video terminal power supplies
Office automation equipment
LCD televisions
PC notebooks
Portable communication equipment
DC/DC converters

Fixed Inductors Procurement Notes

Verify the specific part number suffix against official Central Technologies documentation to confirm RoHS compliance status and exact tolerance ratings. Ensure that the selected variant matches the required shielding type and current specifications for the target application circuit. Cross-reference datasheet parameters such as DCR and Irms before finalizing procurement orders.

Fixed Inductors Selection Notes

Select this component for applications requiring compact shielded inductors with high current ratings. The 1 µH value and low DC resistance make it suitable for switching power supplies. Consider the operating temperature range and physical dimensions when designing the PCB layout. Verify compatibility with reflow soldering profiles specified in the manufacturer's guidelines.

Fixed Inductors Part Context

This component belongs to the CTSD10F series of shielded power inductors from Central Technologies. The series offers various inductance values optimized for different power management needs. The CTSD10F-1R0M specifically provides a 1 µH solution with robust current handling capabilities, fitting into the broader portfolio of surface-mount magnetic components designed for modern electronics manufacturing.
