CTSDB1105F-220M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is 22UH SMD SHLDED POWER INDUCTOR. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for CTSDB1105F-220M
- Description：22UH SMD SHLDED POWER INDUCTOR
- Series：CTSDB1105F
- Mfr：Central Technologies
- Package：Tape & Reel (TR)
- Type：-
- Material - Core：-
- Inductance：22 µH
- Tolerance：±20%
- Current Rating (Amps)：-
- Current - Saturation (Isat)：2.1A
- Shielding：Shielded
- DC Resistance (DCR)：80mOhm Max
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-25°C ~ 75°C
- Inductance Frequency - Test：1 kHz
- Mounting Type：Surface Mount
- Package / Case：Nonstandard
- Supplier Device Package：-
- Size / Dimension：0.591" L x 0.500" W (15.00mm x 12.70mm)
- Height - Seated (Max)：0.236" (6.00mm)
- Features：-
Fixed Inductors datasheet and documents for CTSDB1105F-220M
Fixed Inductors Overview
The CTSDB1105F-220M is a shielded surface-mount power inductor manufactured by Central Technologies. It features a rectangular package with dual-ended terminals and contains one element. The nominal inductance is 22 µH with a ±20% tolerance, measured at 1.0 kHz. The maximum rated current is 900 mA, and the DC resistance is 190 mΩ. The component operates within a temperature range of -40 °C to 125 °C and complies with RoHS standards.
Fixed Inductors Feature Summary
- Shielded construction minimizes electromagnetic interference
- Surface-mount design facilitates automated assembly
- Dual-ended terminal configuration for standard mounting
Fixed Inductors Applications
- Power supply circuits
- General purpose filtering applications
- DC-DC converter modules
Fixed Inductors Procurement Notes
Verify the specific part number against manufacturer documentation to confirm electrical characteristics and physical dimensions. Ensure compliance with environmental regulations such as RoHS requirements before integration into final products. Cross-reference datasheets for accurate thermal and current ratings.
Fixed Inductors Selection Notes
Select this component based on required inductance values and current handling capabilities. Consider the shielded design for noise-sensitive environments. Verify that the operating temperature range aligns with the application's thermal profile. Confirm surface-mount compatibility with existing PCB layouts.
Fixed Inductors Part Context
This component belongs to the CTSDB1105F series, which offers various inductance values ranging from 10 µH to 1500 µH. All parts in this series share similar physical dimensions and shielding characteristics, providing consistent performance across different inductance selections for power electronics designs.
Fixed Inductors Replacement Considerations
Direct substitutes include other CTSDB1105F series variants with matching inductance and current ratings. Verify equivalent specifications from alternative manufacturers if sourcing constraints exist.
