CTSFW1890F-6R8M

Fixed Inductors Overview

The CTSFW1890F-6R8M is a shielded power inductor manufactured by Central Technologies, designed for surface-mount applications. It features a nominal inductance of 6.8 µH with a tolerance of ±20%. The component utilizes a ferrite core and is housed in an 1890 (4532 metric) package size. It is RoHS compliant and lead-free, suitable for general-purpose power supply circuits requiring compact shielding to minimize electromagnetic interference.

Fixed Inductors Feature Summary

• Shielded construction to reduce electromagnetic interference
• Surface-mount design for automated assembly
• Ferrite core material for stable inductance

Fixed Inductors Applications

• Power supply filtering
• DC-DC converter circuits
• General-purpose electronic equipment

Fixed Inductors Procurement Notes

Verify the specific datasheet version from Central Technologies or authorized distributors to confirm current manufacturing status and compliance certifications. Ensure the ordering suffix matches the required packaging configuration. Cross-reference the part number against official catalogs to avoid counterfeit components and confirm availability through verified supply channels.

Fixed Inductors Selection Notes

Select this component when a shielded surface-mount inductor with 6.8 µH nominal value is required. Consider the 1890 package dimensions for board space constraints. Evaluate saturation current and DC resistance specifications against circuit requirements. Confirm RoHS compliance needs are met by the lead-free designation.

Fixed Inductors Part Context

This part belongs to the CTSFW series of shielded power inductors from Central Technologies. The series offers various inductance values and package sizes tailored for power management applications. The 1890 footprint provides a balance between current handling capability and compactness compared to smaller SMD packages.

Fixed Inductors Replacement Considerations

Direct substitutes must match the 6.8 µH inductance, 1890 package dimensions, and shielded construction. Verify equivalent DC resistance and saturation current ratings. Consult Central Technologies for officially recommended alternative part numbers within their portfolio.
