CTSLF0628TF-220M

Fixed Inductors Overview

The CTSLF0628TF-220M is a shielded surface-mount power inductor manufactured by Central Technologies. It features a nominal inductance of 22 µH with a tolerance of 20%. The component has a maximum DC resistance of 104 mΩ and a rated current of 1.3 A. It operates within a temperature range of -40 °C to 85 °C and utilizes a nonstandard rectangular package.

Fixed Inductors Feature Summary

• Shielded construction minimizes electromagnetic interference
• Surface-mount design facilitates automated assembly
• General-purpose power inductor application

Fixed Inductors Applications

• Power supply circuits
• DC-DC converters
• Signal filtering

Fixed Inductors Procurement Notes

Verify the specific suffix 'TF' against official datasheets to confirm shielding and current ratings. Ensure compliance with RoHS directives if required for the target market. Cross-reference the manufacturer's latest documentation to validate the 1.3 A rating and 104 mΩ resistance values before finalizing procurement.

Fixed Inductors Selection Notes

Select this component for applications requiring a 22 µH inductance with moderate current handling capabilities. The shielded design is suitable for environments sensitive to magnetic coupling. Verify that the 1.3 A rated current meets the peak load requirements of the circuit design.

Fixed Inductors Part Context

This part belongs to the CTSLF0628 series of fixed inductors from Central Technologies. The series includes various inductance values and current ratings, all sharing a similar shielded SMD form factor designed for general-purpose power electronics applications.

Fixed Inductors Replacement Considerations

Direct substitutes must match the 22 µH value, 1.3 A current rating, and 104 mΩ resistance. Verify physical footprint compatibility for surface-mount installation.
