CTSLF0745TF-680M

Fixed Inductors Overview

The CTSLF0745TF-680M is a shielded power inductor from the CTSLF0745 series by Central Technologies. It features a fixed inductance of 68 µH with a ±20% tolerance. The component has a rated current of 770 mA and operates within a temperature range of -20°C to +85°C. It utilizes a wirewound construction and is designed for surface-mount device (SMD) applications.

Fixed Inductors Feature Summary

• Shielded design to minimize electromagnetic interference
• Wirewound construction for stable performance
• RoHS compliant manufacturing

Fixed Inductors Applications

• General purpose power supply filtering
• DC-DC converter input/output stages
• Signal processing circuits requiring shielding

Fixed Inductors Procurement Notes

Verify the suffix 'F' indicates RoHS compliance as per manufacturer specifications. Confirm the inductance value of 68 µH and current rating of 770 mA match system requirements. Ensure the SMD package dimensions are compatible with the intended PCB layout. Cross-reference the part number with official Central Technologies documentation to avoid substitution errors.

Fixed Inductors Selection Notes

Select this component when a shielded, low-profile inductor is required for space-constrained designs. The 68 µH value suits moderate frequency switching applications. Consider the 770 mA current limit for load conditions. The operating temperature range supports standard industrial environments. Verify compatibility with automated pick-and-place assembly processes due to its SMD form factor.

Fixed Inductors Part Context

This part belongs to the CTSLF0745 series, which offers a wide range of inductance values from 2.2 µH to 1000 µH. All parts in this series share similar physical characteristics and shielding technology. The series is designed for general-purpose applications where size and EMI reduction are priorities. The specific model provides a mid-range inductance option within this family.

Fixed Inductors Replacement Considerations

Direct substitutes must match the 68 µH inductance, 770 mA current rating, and SMD footprint. Verify that alternative components offer comparable shielding effectiveness and thermal performance. Check for identical RoHS compliance status if environmental regulations apply. Ensure the replacement maintains the same tolerance level of ±20%.
