CTSLF1045TF-100M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is 10UH SMD SHLDED POWER INDUCTOR. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for CTSLF1045TF-100M
- Description：10UH SMD SHLDED POWER INDUCTOR
- Series：CTSLF1045TF
- Mfr：Central Technologies
- Package：Tape & Reel (TR)
- Type：-
- Material - Core：-
- Inductance：10 µH
- Tolerance：±20%
- Current Rating (Amps)：2.5 A
- Current - Saturation (Isat)：3A
- Shielding：Shielded
- DC Resistance (DCR)：36.4mOhm
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-20°C ~ 85°C
- Inductance Frequency - Test：1 kHz
- Mounting Type：Surface Mount
- Package / Case：Nonstandard
- Supplier Device Package：-
- Size / Dimension：0.398" L x 0.398" W (10.10mm x 10.10mm)
- Height - Seated (Max)：0.189" (4.80mm)
- Features：-
Fixed Inductors datasheet and documents for CTSLF1045TF-100M
Fixed Inductors Overview
The CTSLF1045TF-100M is a shielded power inductor from Central Technologies, designed for surface-mount applications. It features a wirewound construction and offers an inductance of 10 µH with a ±20% tolerance. The component operates within a temperature range of -20°C to +85°C. As part of the CTSLF1045 series, it provides general-purpose inductance solutions suitable for various electronic circuits requiring reliable magnetic shielding.
Fixed Inductors Feature Summary
- Shielded power inductor design
- Surface-mount technology (SMD) package
- Wirewound construction
Fixed Inductors Applications
- General purpose inductance applications
- Power supply filtering
- Signal processing circuits
Fixed Inductors Procurement Notes
Verify RoHS compliance status by checking for the 'F' suffix in the ordering part number, as indicated in manufacturer documentation. Confirm that the specific batch matches the required operating temperature range of -20°C to +85°C. Ensure the surface-mount footprint aligns with PCB layout specifications before integration into final assemblies.
Fixed Inductors Selection Notes
Select this component when a 10 µH inductance value with standard tolerance is required for shielded power applications. Consider the wirewound construction for stability and the SMD format for automated assembly processes. Evaluate the operating temperature limits against environmental conditions to ensure long-term reliability in the target electronic system.
Fixed Inductors Part Context
This component belongs to the CTSLF1045 series manufactured by Central Technologies. The series includes various inductance values ranging from 2.2 µH to 1000 µH, all sharing similar physical characteristics and shielding properties. The 'TF' suffix typically denotes specific compliance or packaging variations within the product line.
Fixed Inductors Replacement Considerations
Cross-reference with other CTSLF1045T variants for different inductance values if circuit requirements change. Verify compatibility with existing PCB footprints when substituting with other shielded power inductors from different manufacturers.
