CTSLF1275TF-6R8N

$1.79

Description：SMD SHIELDED POWER INDUCTOR
Series：CTSLF1275
Mfr：Central Technologies
Package：Tape & Reel (TR)

SKU:8602a682e2bd Category: Fixed Inductors Brand: Central Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

CTSLF1275TF-6R8N is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is SMD SHIELDED POWER INDUCTOR. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for CTSLF1275TF-6R8N

Description：SMD SHIELDED POWER INDUCTOR
Series：CTSLF1275
Mfr：Central Technologies
Package：Tape & Reel (TR)
Type：-
Material - Core：-
Inductance：6.8 µH
Tolerance：±30%
Current Rating (Amps)：7.2 A
Current - Saturation (Isat)：5.9A
Shielding：Shielded
DC Resistance (DCR)：13.1mOhm
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：1 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.492" L x 0.492" W (12.50mm x 12.50mm)
Height - Seated (Max)：0.309" (7.85mm)
Features：-

Fixed Inductors datasheet and documents for CTSLF1275TF-6R8N

CTSLF1275TF-6R8N

Fixed Inductors Overview

The CTSLF1275TF-6R8N is a shielded surface-mount power inductor manufactured by Central Technologies. It features a nominal inductance of 6.8 µH and a maximum DC resistance of 13.1 mΩ. The component supports a maximum rated current of 7.2 A and utilizes a nonstandard package footprint.

Fixed Inductors Feature Summary

Magnetic shielding construction to minimize electromagnetic interference
Designed for high-current power supply applications
Surface-mount technology for automated assembly

Fixed Inductors Applications

Power source circuits
DC-DC converters
General power management systems

Fixed Inductors Procurement Notes

Verify the specific manufacturer documentation for the CTSLF1275TF series to confirm exact electrical tolerances, saturation current limits, and thermal characteristics. Ensure that the selected component meets the required operating temperature range and physical dimensions for the target PCB layout before finalizing procurement orders.

Fixed Inductors Selection Notes

Select this component when a shielded power inductor with a 6.8 µH value and high current handling capability is required. Consider the 13.1 mΩ DC resistance for efficiency calculations and verify that the 7.2 A current rating aligns with the peak load requirements of the specific power circuit design.

Fixed Inductors Part Context

This part belongs to the CTSLF1275TF series of shielded power inductors from Central Technologies. The series provides SMD solutions for power electronics, offering magnetic shielding to reduce noise coupling in compact designs suitable for modern electronic equipment.
