CTSPMA5015F-R47M

Fixed Inductors Overview

The CTSPMA5015F-R47M is a shielded molded power inductor from Central Technologies. It features an inductance of 470 nH with a tolerance of ±20%. The component supports a maximum DC current of 8.5 A and a saturation current of 11.2 A. Its maximum DC resistance is 11.2 mOhms. The device operates within a temperature range of -55°C to +125°C. Physical dimensions are 5.0 mm x 5.0 mm x 1.5 mm. It utilizes a non-standard package configuration suitable for surface-mount applications.

Fixed Inductors Feature Summary

• Shielded construction minimizes electromagnetic interference
• High current handling capability up to 8.5 A
• Compact surface-mount design

Fixed Inductors Applications

• Power supply circuits
• DC-DC converters
• Telecommunications equipment

Fixed Inductors Procurement Notes

Verify the specific manufacturer datasheet for the CTSPMA5015F-R47M to confirm exact electrical tolerances and thermal characteristics. Ensure compatibility with automated pick-and-place equipment due to the non-standard package outline. Cross-reference pin assignments and mounting pad layouts with the official footprint documentation before finalizing PCB designs.

Fixed Inductors Selection Notes

Select this component for applications requiring high current density in a compact form factor. The low DC resistance aids in efficiency optimization. Consider the saturation current rating relative to peak load conditions. Verify that the operating temperature range meets environmental requirements. Compare physical dimensions against available board space constraints.

Fixed Inductors Part Context

This part belongs to the SMD power inductor category, designed for modern electronic systems. It represents a solution for space-constrained power management designs. The series offers various inductance values to suit different circuit requirements. Central Technologies focuses on providing reliable passive components for industrial and commercial sectors.

Fixed Inductors Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Consult the manufacturer or authorized distributors for direct equivalents. Ensure any replacement matches the electrical specifications and physical dimensions precisely.
