CTSR0604F-150M

Fixed Inductors Overview

The CTSR0604F-150M is a shielded surface-mount power inductor manufactured by Central Technologies. It features a nominal inductance of 15 µH with a tolerance of ±20%. The component is designed for high-current applications, supporting a maximum rated current of 900 mA and exhibiting a maximum DC resistance of 190 mΩ. It utilizes a nonstandard package form factor suitable for automated assembly processes.

Fixed Inductors Feature Summary

• Shielded magnetic structure to minimize electromagnetic interference
• Surface-mount design optimized for automated PCB assembly
• High current handling capability for power supply circuits

Fixed Inductors Applications

• DC-DC converter output filtering
• Power management integrated circuit (PMIC) input stages
• General-purpose power inductor roles in compact electronics

Fixed Inductors Procurement Notes

Verify the specific manufacturer datasheet for precise thermal derating curves and saturation current limits before finalizing the design. Confirm that the nonstandard package dimensions align with the target PCB footprint and solder mask definitions to ensure reliable reflow soldering outcomes.

Fixed Inductors Selection Notes

Select this component when a compact shielded inductor is required for low-voltage power rails. Ensure the application's peak current demands remain within the 900 mA limit to prevent core saturation. Consider the 190 mΩ resistance impact on overall system efficiency during continuous operation.

Fixed Inductors Part Context

This part belongs to the CTSR series of shielded inductors from Central Technologies. The series provides various inductance values tailored for space-constrained power applications. The 'F' suffix typically denotes specific tolerance or packaging variations within the manufacturer's lineup.

Fixed Inductors Replacement Considerations

Direct substitutes include other 15 µH shielded SMD power inductors with comparable current ratings, such as the CTSR0604F-220M if higher inductance is acceptable. Verify mechanical compatibility and electrical parameters against original specifications.
