CTSRU1048F-101N is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Central Technologies. Its product description is 100UH SMD SHLDED POWER INDUCTOR. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for CTSRU1048F-101N
- Description：100UH SMD SHLDED POWER INDUCTOR
- Series：CTSRU1048F
- Mfr：Central Technologies
- Package：Tape & Reel (TR)
- Type：-
- Material - Core：-
- Inductance：100 µH
- Tolerance：±30%
- Current Rating (Amps)：1.2 A
- Current - Saturation (Isat)：1A
- Shielding：Shielded
- DC Resistance (DCR)：220mOhm Max
- Q @ Freq：26 @ 796kHz
- Frequency - Self Resonant：5MHz
- Ratings：-
- Operating Temperature：-40°C ~ 125°C
- Inductance Frequency - Test：100 kHz
- Mounting Type：Surface Mount
- Package / Case：Nonstandard
- Supplier Device Package：-
- Size / Dimension：0.394" L x 0.394" W (10.00mm x 10.00mm)
- Height - Seated (Max)：0.201" (5.10mm)
- Features：-
Fixed Inductors datasheet and documents for CTSRU1048F-101N
Fixed Inductors Overview
The CTSRU1048F-101N is a fixed inductor manufactured by Central Technologies. It features a shielded design with an inductance of 100 µH and a maximum DC resistance of 220 mOhm. The component supports a current rating of 1.2 A and utilizes a nonstandard package configuration. This inductor is designed for integration into electronic circuits requiring reliable magnetic shielding and specific electrical characteristics.
Fixed Inductors Feature Summary
- Shielded construction to minimize electromagnetic interference
- Fixed inductance value suitable for stable circuit operation
- Nonstandard physical package format
Fixed Inductors Applications
- Aerospace electronics systems
- General industrial electronic circuits
- Power supply filtering applications
Fixed Inductors Procurement Notes
Verify the exact physical dimensions against your PCB footprint requirements, as the package is classified as nonstandard. Confirm that the 1.2 A current rating and 220 mOhm resistance meet your circuit's thermal and efficiency specifications before finalizing procurement.
Fixed Inductors Selection Notes
Select this component when a shielded inductor with 100 µH inductance is required for aerospace or industrial environments. Ensure the nonstandard package fits your assembly constraints. Compare performance against standard packages if space allows, but prioritize the shielding benefits for noise-sensitive applications.
Fixed Inductors Part Context
Central Technologies specializes in high-quality inductive components and magnets. Established in 1994, the company serves industries such as aerospace and general electronics. The CTSRU1048F-101N represents their capability to provide specialized inductive solutions with specific shielding and electrical properties.
Fixed Inductors Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with existing designs carefully if sourcing alternatives.
