CWN-320-50-0000

Headers, Male Pins Overview

The CWN-320-50-0000 is a vertical pin header connector manufactured by CW Industries. It features 50 positions arranged in two rows with a 0.100-inch (2.54mm) pitch. Designed for through-hole mounting, the connector utilizes phosphor bronze contacts with gold plating on the mating surfaces and nickel plating on the tails. The housing is constructed from blue thermoplastic material rated UL94 V-0. This component supports a maximum current rating of 1A and operates within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Vertical board-to-cable or wire configuration with push-pull locking mechanism
• Gold-plated phosphor bronze contacts ensuring reliable signal transmission
• Blue thermoplastic insulation with integrated keying slots and mounting flanges

Headers, Male Pins Applications

• Industrial control system interconnections
• Consumer electronics assembly
• General-purpose circuit board wiring

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official documentation to confirm exact contact length and termination specifications. Confirm availability status as distribution data may indicate obsolescence or limited stock. Ensure compatibility with mating receptacles regarding row spacing and housing dimensions before procurement.

Headers, Male Pins Selection Notes

Select this connector when a vertical, high-density header is required for through-hole PCB assembly. Ensure the mating device matches the 50-position count and 2.54mm pitch. Verify that the application environment remains within the specified -55°C to 125°C operating temperature range and does not exceed the 1A current rating per contact.

Headers, Male Pins Part Context

This part belongs to the CWN series of rectangular connectors from CW Industries. The series offers various configurations including straight and right-angle options with different pin counts. The CWN-320 variant specifically denotes a vertical orientation with standard contact lengths suitable for general board-to-wire applications.

Headers, Male Pins Replacement Considerations

Cross-reference with other manufacturers' 50-position, 2.54mm pitch vertical headers. Ensure mechanical footprint, pinout arrangement, and locking mechanism compatibility are verified before substitution.
