CWN-350-16-0000

Headers, Male Pins Overview

The CWN-350-16-0000 is a vertical header connector manufactured by CW Industries, featuring 16 positions in a dual-row configuration. It utilizes a 2.54mm (0.100 inch) pitch for mating contacts and includes an installation flange for secure board mounting. The component employs through-hole termination with solder pins and offers gold-plated mating surfaces to ensure reliable electrical conductivity. Designed for robust performance, it supports a wide operating temperature range from -55°C to 125°C and meets UL94 V-0 flammability standards for the insulator.

Headers, Male Pins Feature Summary

• Vertical orientation with integrated installation flange for stable PCB attachment
• Gold-plated contact surfaces ensuring durable signal transmission
• Through-hole solder termination compatible with standard assembly processes

Headers, Male Pins Applications

• General-purpose electronic circuit interconnections
• Industrial control panel wiring
• Consumer electronics board-to-board connections

Headers, Male Pins Procurement Notes

Verify current availability status as this part number may be subject to obsolescence or discontinuation notices from the manufacturer. Confirm that the specific lot date codes meet project requirements before finalizing orders. Ensure compatibility with existing PCB footprints and mating connectors during the procurement phase to avoid integration issues.

Headers, Male Pins Selection Notes

Select this component when a vertical, low-profile header with high reliability is required. The 16-position count and 2.54mm pitch are standard for many legacy designs. Consider the end-of-life status when planning long-term production runs. Verify that the thermal rating of 125°C aligns with the operational environment of the target application.

Headers, Male Pins Part Context

This connector belongs to the CWN series of headers from CW Industries, designed for general interconnect needs. It serves as a male pin header variant within the broader family of rectangular connectors. The specific model indicates a 16-pin configuration, distinguishing it from other pin counts in the same product line while sharing common mechanical and electrical characteristics.

Headers, Male Pins Replacement Considerations

Check for direct cross-references from CW Industries or equivalent suppliers offering identical 16-position, 2.54mm pitch vertical headers. Ensure any substitute matches the flange design and solder tail specifications for proper PCB fit.
