CWN-350-26-0000

Headers, Male Pins Overview

The CWN-350-26-0000 is a vertical board-to-board or wire-to-board header connector manufactured by CW Industries. It features a male pin configuration with 26 positions arranged in two rows, providing a total contact count of 26. The connector utilizes a 0.100 inch (2.54mm) pitch for both row and contact spacing. Designed for through-hole termination, it incorporates a shrouded housing with four-wall shielding to ensure proper alignment and protection. The unit includes an installation flange and keyway for secure mounting.

Headers, Male Pins Feature Summary

• Vertical orientation with male pin contacts for reliable board interconnection
• Shrouded design featuring four-wall shielding to prevent misalignment
• Integrated installation flange and keyway for precise PCB mounting

Headers, Male Pins Applications

• General-purpose electronic circuit board interconnections
• Wire-to-board assembly applications requiring vertical headers
• Industrial control systems utilizing standard 2.54mm pitch connectors

Headers, Male Pins Procurement Notes

Verify the specific part number against official manufacturer documentation to confirm current availability status. Check for any product change notices or obsolescence alerts issued by CW Industries prior to procurement. Ensure that the required quantity matches project needs as supply chain conditions may vary. Confirm that the packaging type aligns with assembly requirements.

Headers, Male Pins Selection Notes

Select this component when a vertical, shrouded header with four-wall shielding is required for 26-position connections. Ensure the application supports through-hole soldering processes and operates within the specified temperature range. Verify that the mating connector interface matches the 0.100 inch pitch and male pin configuration. Consider mechanical stability provided by the integrated flange for robust mounting.

Headers, Male Pins Part Context

This component belongs to the CWN series of header connectors from CW Industries, designed for rectangular interconnect solutions. The series offers various position counts and configurations to suit different electronic assembly needs. This specific model represents a standard vertical header option within the broader portfolio of board-to-board and wire-to-board connectivity products.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Cross-referencing with other manufacturers requires careful verification of pitch, shielding, and mounting characteristics.
