CWN-521-60-0060

Headers, Male Pins Overview

The CWN-521-60-0060 is a shrouded header connector manufactured by CW Industries, designed for right-angle through-hole mounting. It features 60 positions arranged in a single row with a 0.100 inch (2.54mm) pitch. The connector utilizes male pin contacts made of phosphor bronze, terminated via wire wrap soldering methods. Rated for 1A current and 500VDC dielectric strength, it operates within a temperature range of -55°C to 125°C. The housing is constructed from blue thermoplastic material rated UL94 V-0 for flammability. Key mechanical features include keying slots and short latch lock or eject hooks to secure mating connections.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting configuration for space-efficient board integration
• Shrouded design with keying slots to ensure correct polarized alignment
• Short latch lock or eject hooks provide secure mating retention
• Wire wrap termination style ensures reliable electrical connection

Headers, Male Pins Applications

• Industrial control panel interconnections
• Consumer electronics internal wiring harnesses
• Telecommunications equipment signal routing
• Automotive electronic module connections

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official datasheets to confirm exact contact plating thickness and housing color variations. Confirm that the right-angle orientation matches the PCB layout requirements. Check for RoHS compliance status if environmental regulations apply to the final assembly. Ensure the wire wrap termination method is compatible with the manufacturing process capabilities.

Headers, Male Pins Selection Notes

Select this component when a right-angle, shrouded header with 60 positions is required. The 2.54mm pitch suits standard digital signal applications. Verify that the 1A current rating meets the circuit load requirements. Consider the thermal stability up to 125°C for high-temperature environments. Ensure the PCB hole pattern accommodates the through-hole pins and mounting features.

Headers, Male Pins Part Context

This part belongs to the CWN series of commercial headers from CW Industries. The series offers various position counts and orientations. The CWN-521-60-0060 specifically addresses the need for high-density right-angle connections. It complements other series like CWR for different mounting styles. The product line focuses on reliable interconnect solutions for general electronic assemblies.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Cross-reference with CW Industries' updated catalog for potential obsolescence management. Verify mechanical compatibility before considering alternative manufacturers.
