CWR-170-50-0003

Description：CONN EDGE DUAL FMALE 50POS .100
Series：170
Mfr：CW Industries
Package：Bulk

SKU:d0c03d3ccc75 Category: Edgeboard Connectors Brand: CW Industries

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

CWR-170-50-0003 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists CW Industries. Its product description is CONN EDGE DUAL FMALE 50POS .100. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for CWR-170-50-0003

Description：CONN EDGE DUAL FMALE 50POS .100
Series：170
Mfr：CW Industries
Package：Bulk
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：25
Number of Positions：50
Card Thickness：0.032" ~ 0.070" (0.81mm ~ 1.78mm)
Number of Rows：2
Pitch：0.100" (2.54mm)
Read Out：Dual
Features：-
Mounting Type：Free Hanging (In-Line)
Termination：IDC
Contact Material：Phosphor Bronze
Contact Finish：Tin-Lead
Contact Finish Thickness：100.0µin (2.54µm)
Contact Type：Cantilever
Color：Blue
Flange Feature：-
Operating Temperature：-55°C ~ 125°C

Edgeboard Connectors datasheet and documents for CWR-170-50-0003

CWR-170-50-0003

Edgeboard Connectors Overview

The CWR-170-50-0003 is a commercial-grade card edge connector manufactured by CW Industries. It features a dual female configuration with 50 positions and a 2.54 mm (0.1 inch) pitch. Designed for ribbon cable applications, this component utilizes an IDC termination method and is intended for straight cable mount or free-hanging installation styles.

Edgeboard Connectors Feature Summary

Dual female contact configuration for reliable signal transmission
IDC termination mechanism for efficient ribbon cable connection
Straight orientation design suitable for direct cable mounting

Edgeboard Connectors Applications

Ribbon cable interconnects in commercial electronics
Card edge connector assemblies requiring IDC termination
Free-hanging cable management systems

Edgeboard Connectors Procurement Notes

Verify the specific manufacturer part number against official CW Industries documentation to confirm compatibility. Ensure that the required pin count and termination type match the target application specifications before procurement. Cross-reference datasheets for environmental ratings and mechanical constraints.

Edgeboard Connectors Selection Notes

Select this component when a dual-row female card edge connector with IDC termination is required. The 50-position layout and 2.54 mm pitch define its physical interface. Confirm that the straight mounting style aligns with the system's spatial requirements and cable routing needs.

Edgeboard Connectors Part Context

This part belongs to the CWR series of headers and wire housings from CW Industries. It is categorized under standard card edge connectors designed for commercial use. The product line focuses on providing reliable interconnect solutions for ribbon cables in various electronic assemblies.
