CX532Z-A5B3C5-70-20.0D18

Crystals Overview

The CX532Z-A5B3C5-70-20.0D18 is a parallel fundamental quartz crystal manufactured by Cardinal Components Inc. It operates at a nominal frequency of 20.0 MHz with a load capacitance of 18 pF and an equivalent series resistance of 70 Ohms. The component features a frequency stability of ±50 ppm and a tolerance of ±30 ppm. It supports a wide operating temperature range from -40°C to +85°C and utilizes a surface mount ceramic package. The unit is RoHS compliant, lead-free, and supplied in tape and reel packaging.

Crystals Feature Summary

• Surface mount ceramic construction for compact integration
• Wide industrial temperature rating for environmental resilience
• RoHS compliant and lead-free manufacturing process

Crystals Applications

• Industrial control systems requiring stable clock signals
• Communication equipment utilizing 20 MHz reference frequencies
• Embedded microcontroller clock sources

Crystals Procurement Notes

Verify the specific ordering suffixes against the manufacturer's current CX532 series datasheet to ensure alignment with required frequency tolerance and temperature range specifications. Confirm that the tape and reel packaging format matches automated assembly requirements. Cross-reference the RoHS compliance status with current regulatory standards for the target market before finalizing procurement orders.

Crystals Selection Notes

Select this component when a 20 MHz fundamental frequency is required within a small surface mount footprint. Ensure the circuit design accommodates the specified 18 pF load capacitance to maintain accurate frequency performance. Verify that the operational environment remains within the -40°C to +85°C range to guarantee long-term stability and reliability.

Crystals Part Context

This part belongs to the CX532 series of ceramic surface mount crystals from Cardinal Components Inc. The series offers various package options and frequency ranges designed for general-purpose timing applications. The Z suffix indicates tape and reel packaging, while the A5 code specifies the extended temperature range capability.

Crystals Replacement Considerations

Direct substitutes include other Cardinal Components CX532 series parts with matching 20.0 MHz frequency and 18 pF load capacitance. Verify that alternative components share the same physical dimensions and pin configuration to ensure mechanical compatibility.
