CY95F563KPFT-G-UNERE2

Microcontrollers Overview

The CY95F563KPFT-G-UNERE2 is an 8-bit microcontroller from Infineon Technologies, belonging to the MM-LEGACY MM series. It utilizes the F2MC-8FX core and features 12 kB of Flash program memory and 496 bytes of data RAM. The device operates with a maximum clock frequency of 16.25 MHz and supports a supply voltage range of 2.4 V to 5.5 V. It includes six ADC channels with 8-bit and 10-bit resolution options. The component is housed in a TSSOP-20 package and offers 16 I/O pins. It supports UART interfaces and functions within a temperature range of -40°C to +85°C.

Microcontrollers Feature Summary

• Integrates F2MC-8FX 8-bit core for efficient processing
• Includes built-in analog-to-digital conversion capabilities
• Supports serial communication via UART interface

Microcontrollers Applications

• General-purpose embedded control systems
• Industrial automation controllers
• Consumer electronics devices

Microcontrollers Procurement Notes

Verify current availability status as this component may be subject to limited supply or end-of-life conditions. Confirm that the specific suffix matches required packaging and environmental specifications. Ensure compatibility with existing design constraints before procurement. Check for official replacement recommendations if discontinuation is confirmed.

Microcontrollers Selection Notes

Select this part for applications requiring an 8-bit architecture with moderate memory capacity. Consider the TSSOP-20 package size for space-constrained designs. Evaluate the 16.25 MHz speed against processing requirements. Verify voltage levels match system power rails. Assess peripheral needs such as ADC channels and UART ports.

Microcontrollers Part Context

This microcontroller is part of Infineon's legacy MM series, designed for cost-sensitive applications. It shares architectural similarities with other F2MC-8FX based devices. The series emphasizes reliability and ease of integration for standard control tasks. Development tools and documentation are available through official channels.

Microcontrollers Replacement Considerations

Consult official datasheets for direct pin-compatible substitutes within the same family. Verify electrical characteristics and memory sizes when selecting alternatives.
