CYT3BB8CEBR0AESGST is listed in the Microcontrollers range at ChipApex. The manufacturer field lists Infineon Technologies. Its product description is IC MCU 32BT 4.063MB FLSH 176QFP. Review the specifications below when checking this part for your BOM.
Microcontrollers specifications for CYT3BB8CEBR0AESGST
- Description：IC MCU 32BT 4.063MB FLSH 176QFP
- Series：Traveo™ T2G
- Mfr：Infineon Technologies
- Package：Tape & Reel (TR)
- Core Processor：ARM® Cortex®-M0+, ARM® Cortex®-M7F
- Core Size：32-Bit Dual-Core
- Speed：100MHz, 250MHz
- Connectivity：eMMC/SD/SDIO, I2C, IrDA, LINbus, Microwire, QSPI, SmartCard, SPI, SSP, UART/USART, USB
- Peripherals：Brown-out Detect/Reset, DMA, I2S, LVD, POR, PWM, Temp Sensor, WDT
- Number of I/O：148
- Program Memory Size：4.063MB (4.063M x 8)
- Program Memory Type：FLASH
- EEPROM Size：256K x 8
- RAM Size：768K x 8
- Voltage - Supply (Vcc/Vdd)：2.7V ~ 5.5V
- Data Converters：A/D 82x12b SAR
- Oscillator Type：External, Internal
- Operating Temperature：-40°C ~ 105°C (TA)
- Mounting Type：Surface Mount
- Supplier Device Package：176-TEQFP (24x24)
- Package / Case：176-LQFP Exposed Pad
- Grade：-
- Qualification：-
Microcontrollers datasheet and documents for CYT3BB8CEBR0AESGST
Microcontrollers Overview
The CYT3BB8CEBR0AESGST is an ARM microcontroller from the Traveo T2G family, featuring a dual-core architecture with ARM Cortex-M7F and Cortex-M0+ processors. It operates at clock speeds up to 250 MHz and includes 4.063 MB of FLASH memory. The device supports high-performance processing for automotive applications.
Microcontrollers Feature Summary
- Dual-core architecture combining ARM Cortex-M7F and Cortex-M0+ processors
- High-speed 32-bit processing capability reaching 250 MHz
- Integrated 4.063 MB FLASH memory for code storage
Microcontrollers Applications
- Automotive body electronics control
- Infotainment system processing
- Advanced driver assistance systems (ADAS) preprocessing
Microcontrollers Procurement Notes
Verify component authenticity through authorized Infineon distributors or certified partners. Confirm RoHS compliance status and moisture sensitivity level prior to assembly. Check for end-of-life notifications as discontinuation may affect long-term supply chain stability. Ensure packaging specifications match reflow soldering requirements.
Microcontrollers Selection Notes
Select this model when dual-core performance with Cortex-M7F efficiency is required. Consider the 4.063 MB FLASH capacity for complex application firmware. Evaluate thermal management needs for 250 MHz operation. Compare against other Traveo T2G variants for pin compatibility and peripheral integration requirements.
Microcontrollers Part Context
This component belongs to the Traveo T2G series, designed for automotive body and gateway applications. It integrates high-performance computing with functional safety features. The series targets demanding embedded control tasks requiring real-time processing and large memory footprints.
Microcontrollers Replacement Considerations
Consult official Infineon documentation for qualified substitutes within the Traveo T2G family. Verify pin-to-pin compatibility and software migration paths before transitioning to alternative part numbers.
