CZP2AFTTD300P

$0.14

Description：FERRITE BEAD 30 OHM 0805 1LN
Series：CZP
Mfr：KOA Speer Electronics, Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:35405434fa00 Category: Ferrite Beads and Chips Brand: KOA Speer Electronics, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：FERRITE BEAD 30 OHM 0805 1LN
Series：CZP
Mfr：KOA Speer Electronics, Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
Filter Type：Power Line
Number of Lines：1
Impedance @ Frequency：30 Ohms @ 100 MHz
Current Rating (Max)：4A
DC Resistance (DCR) (Max)：15mOhm
Ratings：-
Operating Temperature：-55°C ~ 125°C
Package / Case：0805 (2012 Metric)
Mounting Type：Surface Mount
Height (Max)：0.043" (1.10mm)
Size / Dimension：0.079" L x 0.047" W (2.00mm x 1.20mm)
Features：-

Download product information

CZP2AFTTD300P

Overview

The CZP2AFTTD300P is a multilayer power ferrite bead manufactured by KOA Speer Electronics, Inc. It features an 0805 (2012 metric) surface-mount package with dimensions of 2.0 mm length, 1.25 mm width, and 0.9 mm height. The component provides an impedance of 30 Ohms at a test frequency of 100 MHz with a tolerance of 25%. It supports a maximum DC current of 4 A and has a maximum DC resistance of 15 mOhms. The operating temperature range extends from -55°C to +125°C.

Feature Summary

Multilayer construction designed for high-current power line applications
Surface-mount termination compatible with standard SMD/SMT assembly processes
Capable of handling significant DC bias currents while maintaining signal integrity

Applications

Power supply output filtering
High-current signal line noise suppression
DC-DC converter circuit protection

Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to ensure correct impedance and current ratings. Confirm RoHS compliance status and packaging options such as cut tape or reel availability directly with authorized distributors. Cross-reference the Mouser part number 660-CZP2AFTTD300P for accurate sourcing details.

Selection Notes

Select this component when high DC current capacity is required alongside moderate impedance values. The 0805 package offers a balance between current handling capability and board space efficiency. Ensure the application environment stays within the specified -55°C to +125°C operational temperature range for reliable performance.

Part Context

This part belongs to the CZP series of multilayer power ferrite beads from KOA Speer. These components are engineered to suppress electromagnetic interference in circuits carrying substantial direct current. The series utilizes advanced ceramic materials to provide stable impedance characteristics under varying load conditions.

Replacement Considerations

Compatible substitutes include other 0805 ferrite beads with similar 30 Ohm impedance and 4A current ratings. Verify physical footprint compatibility and thermal characteristics before substitution.
