D24D15-1WH2 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists HenLv Power. Its product description is DC DC CONVERTER 1W. Review the specifications below when checking this part for your BOM.
DC DC Converters specifications for D24D15-1WH2
- Description：DC DC CONVERTER 1W
- Series：*
- Mfr：HenLv Power
- Package：Case
- Type：Isolated Module
- Number of Outputs：2
- Voltage - Input (Min)：22.8V
- Voltage - Input (Max)：25.2V
- Voltage - Output 1：15V
- Voltage - Output 2：-15V
- Voltage - Output 3：-
- Voltage - Output 4：-
- Current - Output (Max)：33mA
- Power (Watts)：1 W
- Voltage - Isolation：-
- Applications：Industrial
- Features：-
- Operating Temperature：-40°C ~ 85°C
- Efficiency：80 ~ 88%
- Mounting Type：Through Hole
- Package / Case：Module
- Size / Dimension：0.80" L x 0.39" W x 0.28" H (20.4mm x 10.0mm x 7.0mm)
- Supplier Device Package：-
- Control Features：-
- Approval Agency：CE
- Standard Number：-
DC DC Converters datasheet and documents for D24D15-1WH2
