DAC1003D160HW/C1,5

$9.49

Description：IC DAC 10BIT A-OUT 80HTQFP
Series：-

SKU:8d6aba3c50f0 Category: Digital to Analog Converters (DAC) Brand: Renesas Electronics Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

DAC1003D160HW/C1,5 is listed in the Digital To Analog Converters range at ChipApex. The manufacturer field lists Renesas Electronics Corporation. Its product description is IC DAC 10BIT A-OUT 80HTQFP. Review the specifications below when checking this part for your BOM.

Digital To Analog Converters specifications for DAC1003D160HW/C1,5

Description：IC DAC 10BIT A-OUT 80HTQFP
Series：-
Mfr：Renesas Electronics Corporation
Package：Tape & Reel (TR)
Number of Bits：10
Number of D/A Converters：2
Settling Time：16ns (Typ)
Output Type：Current - Unbuffered
Differential Output：Yes
Data Interface：Parallel
Reference Type：External, Internal
Voltage - Supply, Analog：3V ~ 3.6V
Voltage - Supply, Digital：3V ~ 3.6V
INL/DNL (LSB)：±0.2, ±0.1
Architecture：Binary-Weighted DAC, String DAC
Operating Temperature：-40°C ~ 85°C
Package / Case：80-TQFP Exposed Pad
Supplier Device Package：80-HTQFP (12x12)
Mounting Type：Surface Mount
Grade：-
Qualification：-

Digital To Analog Converters datasheet and documents for DAC1003D160HW/C1,5

DAC1003D160HW/C1,5

Digital To Analog Converters Overview

The DAC1003D160HW/C1:5 is a dual 10-bit digital-to-analog converter manufactured by Renesas Electronics Corporation. It features an internal sampling rate up to 160MHz and a typical settling time of 16ns. The device provides unbuffered current outputs with differential capability, supporting parallel data interfaces. Packaged in an 80-HTQFP format, it integrates low-noise capacitor-free phase-locked loops and interpolation filters for precision analog signal generation.

Digital To Analog Converters Feature Summary

Dual 10-bit resolution architecture
Internal sampling rate up to 160MHz
Low noise capacitor-free integrated phase-locked loop
Two interpolation filters

Digital To Analog Converters Applications

Broadband wireless systems transmitters
Precision analog signal generation
Data acquisition systems

Digital To Analog Converters Procurement Notes

Verify the complete part number including the suffix /C1:5 to ensure correct package and temperature range specifications. Confirm that the source document explicitly identifies Renesas Electronics Corporation as the manufacturer. Check datasheets for interface compatibility and output configuration requirements before procurement.

Digital To Analog Converters Selection Notes

Select this component when high-speed dual-channel conversion is required. The 160MHz sampling rate suits broadband applications. Ensure system design accommodates unbuffered current outputs and differential signaling. Verify power supply constraints align with the device's low-power characteristics and PLL integration.

Digital To Analog Converters Part Context

This device belongs to the DAC1003 series of high-speed digital-to-analog converters. It shares architectural similarities with other models in the family but offers specific 10-bit resolution and 160MHz performance metrics. The HTQFP package distinguishes it from other pinout configurations within the broader product line.
