DDC316CGXGR

Analog To Digital Converters (ADC) Overview

The DDC316CGXGR is a specialized integrated circuit manufactured by Texas Instruments, classified as a Current Digital Converter (CDC). It features a 16-channel architecture designed for high-precision current input applications. The device operates with a sampling rate of 100k samples per second and utilizes a serial data interface for communication. It is housed in a 64-NFBGA package with dimensions of 8x8 mm, suitable for surface mount installation. The component functions within an operating temperature range of 0°C to 70°C and complies with RoHS3 standards.

Analog To Digital Converters (ADC) Feature Summary

• Integrates 16 channels of current-to-digital conversion capability within a single compact package.
• Supports serial data output interfaces for streamlined system connectivity.
• Engineered for industrial-grade operation across standard commercial temperature ranges.

Analog To Digital Converters (ADC) Applications

• Industrial process control systems requiring multi-channel current monitoring
• Sensor signal conditioning for precision measurement devices
• Data acquisition systems utilizing current-mode transducers

Analog To Digital Converters (ADC) Procurement Notes

Verify the specific suffix 'CGXGR' against official Texas Instruments documentation to confirm pinout, thermal characteristics, and packaging details. Ensure compatibility with existing board layouts and thermal management strategies before integration. Cross-reference the manufacturer part number with authorized distributor catalogs to validate authenticity and supply chain integrity.

Analog To Digital Converters (ADC) Selection Notes

Select this component when designing systems that require direct digitization of multiple low-level current signals without external amplification stages. Consider the 64-pin NFBGA footprint for space-constrained designs. Evaluate the 100kS/s throughput against application bandwidth requirements to ensure adequate sampling density for the target signal frequencies.

Analog To Digital Converters (ADC) Part Context

This device belongs to the DDC316 family of current-input analog-to-digital converters from Texas Instruments. These components are engineered to simplify the interface between current-output sensors and digital processing units. The family offers varying channel counts and package options to accommodate different density and performance needs in industrial instrumentation.

Analog To Digital Converters (ADC) Replacement Considerations

Consult the Texas Instruments DDC316 datasheet for officially listed alternative part numbers or pin-compatible variants. Verify functional equivalence regarding channel count, sampling rate, and interface protocols before substituting. Do not assume cross-compatibility with other ADC families without explicit manufacturer confirmation.
