DEA162600BT-1258C2

$0.45

Description：RF FILTER BAND PASS 2.6GHZ 0603
Series：DEA
Mfr：TDK Corporation
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:17fc1d695262 Category: RF Filters Brand: TDK Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RF FILTER BAND PASS 2.6GHZ 0603
Series：DEA
Mfr：TDK Corporation
Package：Tape & Reel (TR),Cut Tape (CT)
Frequency：2.6GHz Center
Bandwidth：200MHz
Filter Type：Band Pass
Ripple：-
Insertion Loss：2.2dB
Mounting Type：Surface Mount
Package / Case：0603 (1608 Metric), 4 PC Pad
Size / Dimension：0.063" L x 0.031" W (1.60mm x 0.80mm)
Height (Max)：0.028" (0.70mm)

Download product information

DEA162600BT-1258C2

Overview

The DEA162600BT-1258C2 is a signal conditioning LTCC bandpass filter manufactured by TDK Corporation. It operates at a center frequency of 2500-2700MHz with a bandwidth of 200MHz. The device features low insertion loss of 2.2dB and utilizes a compact 0603 surface mount package with four PC pads. This component is designed for high-frequency applications requiring precise RF filtering.

Feature Summary

LTCC construction for stable high-frequency performance
Compact 0603 surface mount footprint
Low insertion loss characteristics

Applications

High-frequency RF systems
Wireless communication modules
Signal conditioning circuits

Procurement Notes

Verify current manufacturing status as the part may be obsolete. Confirm availability of recommended substitutes from the manufacturer if direct procurement is not possible. Ensure compatibility with existing PCB layouts due to the specific 0603 package dimensions.

Selection Notes

Select this component for applications requiring a 2.6GHz center frequency bandpass filter. Consider the 200MHz bandwidth and 2.2dB insertion loss specifications against system requirements. The 0603 package size is suitable for space-constrained designs.

Part Context

This component belongs to TDK's RF filter portfolio, specifically utilizing LTCC technology for signal conditioning. It is categorized under wireless connection products and passive components, targeting markets with increasing demand for compact RF solutions in IoT and mobile devices.

Replacement Considerations

The DEA162600BT-1258C2 is listed as obsolete. Check for MFR-recommended substitute part numbers provided by distributors or TDK directly to ensure functional equivalence in design.
