DEA162690LT-5064A1

$0.22

Description：RF FILTER LO PASS 1.6945GHZ 0603
Series：DEA
Mfr：TDK Corporation
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:af3c099da2be Category: RF Filters Brand: TDK Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RF FILTER LO PASS 1.6945GHZ 0603
Series：DEA
Mfr：TDK Corporation
Package：Tape & Reel (TR),Cut Tape (CT)
Frequency：1.6945GHz Center
Bandwidth：1.991GHz
Filter Type：Low Pass
Ripple：-
Insertion Loss：0.18dB
Mounting Type：Surface Mount
Package / Case：0603 (1608 Metric), 4 PC Pad
Size / Dimension：0.063" L x 0.031" W (1.60mm x 0.80mm)
Height (Max)：0.028" (0.70mm)

Download product information

DEA162690LT-5064A1

Overview

The DEA162690LT-5064A1 is a low-pass RF filter manufactured by TDK Corporation, utilizing Low-Temperature Co-Fired Ceramic (LTCC) technology. It features a center frequency of 1.6945GHz and a bandwidth of 1.991GHz. The component exhibits an insertion loss of 0.18dB and is housed in a 0603 surface-mount package with four printed circuit board connections. Its physical dimensions are 1.60mm in length, 0.80mm in width, and a maximum height of 0.70mm.

Feature Summary

Utilizes LTCC technology for low insertion loss and latency performance
Designed for high-frequency RF signal filtering applications
Supports surface-mount assembly in compact 0603 packages

Applications

RF connectivity systems
Wireless base station components
Cellular infrastructure modules

Procurement Notes

Verify the specific part number against official TDK documentation to confirm current availability status. Check for any Product Change Notifications regarding packaging or material composition. Ensure compatibility with existing design specifications before procurement. Confirm RoHS compliance requirements match project standards.

Selection Notes

Select this component based on its specific center frequency and bandwidth requirements for low-pass filtering. Consider the 0603 footprint constraints and surface-mount installation method. Evaluate the insertion loss characteristics against system sensitivity needs. Verify thermal operating range suitability for the intended environment.

Part Context

This component belongs to the DEA series of RF filters from TDK Corporation. It is designed for use in wireless connectivity and cellular applications. The product utilizes advanced ceramic materials to achieve precise filtering characteristics in a miniature form factor suitable for modern electronic devices.

Replacement Considerations

DEA162690LT-5051B1 is listed as a manufacturer-recommended substitute. LPF1608LL52R2500A by Pulse Electronics is identified as a similar alternative. Verify electrical parameters and pin configurations before substitution.
