DEA453960BT-3007B1

Overview

The DEA453960BT-3007B1 is a surface-mount bandpass filter designed for Ultra-Wideband (UWB) applications. It operates within a frequency range of 3.1 GHz to 4.9 GHz, with a center frequency of 3.96 GHz and a bandwidth of 1.584 GHz. The component exhibits an insertion loss of 1.7 dB and functions reliably across a temperature range of -40°C to +85°C. It utilizes a compact SMD package with a maximum height of 1.00 mm.

Feature Summary

• Optimized for Ultra-Wideband signal processing
• Compact surface-mount design for space-constrained layouts

Applications

• Ultra-Wideband communication systems
• Wireless data transmission modules
• RF front-end filtering in consumer electronics

Procurement Notes

Verify the specific datasheet version and packaging details before procurement. Confirm that the operating temperature range and electrical specifications align with the target application requirements. Ensure compatibility with standard surface-mount assembly processes.

Selection Notes

Select this component for designs requiring precise bandpass filtering in the UWB spectrum. Consider the low insertion loss and small form factor when integrating into high-density circuit boards. Validate performance against system-level noise and interference constraints.

Part Context

This part belongs to TDK's DEA series of RF filters. It is engineered to provide stable signal integrity in high-frequency environments. The component supports modern wireless standards requiring wide bandwidth capabilities.

Replacement Considerations

No public confirmed substitute part numbers are available.
