DETN02N-12N

DETN02N-12N is listed in the DC DC Converters range at ChipApex. The manufacturer field lists MEAN WELL USA Inc.. Its product description is DC DC CONVERTER +/-12V 1.99W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for DETN02N-12N

• Description：DC DC CONVERTER +/-12V 1.99W
• Series：DETN02-N (2W)
• Mfr：MEAN WELL USA Inc.
• Package：Bulk
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：21.6V
• Voltage - Input (Max)：26.4V
• Voltage - Output 1：12V
• Voltage - Output 2：-12V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：83mA, 83mA
• Power (Watts)：1.99 W
• Voltage - Isolation：3 kV
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 85°C
• Efficiency：82%
• Mounting Type：Surface Mount
• Package / Case：12-SMD Module, 10 Leads
• Size / Dimension：0.60" L x 0.43" W x 0.36" H (15.2mm x 10.9mm x 9.1mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：CE, EAC, UKCA
• Standard Number：-
• Grade：-
• Qualification：-
