DFKF-18-0003

$2.97

Description：CMC 1.2A 2LN TH
Series：DFKF
Mfr：SCHURTER Inc.
Package：Bulk

SKU:04cdcdd469b1 Category: Common Mode Chokes Brand: SCHURTER Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

DFKF-18-0003 is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists SCHURTER Inc.. Its product description is CMC 1.2A 2LN TH. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for DFKF-18-0003

Description：CMC 1.2A 2LN TH
Series：DFKF
Mfr：SCHURTER Inc.
Package：Bulk
Filter Type：-
Number of Lines：2
Current Rating (Max)：1.2A
DC Resistance (DCR) (Max)：200mOhm
Voltage Rating - DC：-
Voltage Rating - AC：440V
Operating Temperature：-25°C ~ 100°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：0.717" L x 0.701" W (18.20mm x 17.80mm)
Height (Max)：-
Package / Case：Radial - 4 Leads
Inductance @ Frequency：-

Common Mode Chokes datasheet and documents for DFKF-18-0003

DFKF-18-0003

Common Mode Chokes Overview

The DFKF-18-0003 is a compensated common mode choke manufactured by Schurter Inc. It features a current rating of 1.2A and a maximum DC resistance of 200mOhm. The component supports an AC voltage rating of 440V and operates within a temperature range of -25°C to 100°C. Designed for through-hole mounting, this inductor serves as a linear choke with a flat design profile.

Common Mode Chokes Feature Summary

Compensated common mode choke design
Flat physical structure
Through-hole termination style

Common Mode Chokes Applications

Common mode noise suppression
Linear choke applications

Common Mode Chokes Procurement Notes

Verify the specific datasheet version and RoHS compliance status directly with Schurter Inc. or authorized distributors before procurement. Confirm that the 1.2A current rating and 440V AC voltage specifications align with your circuit requirements. Ensure the through-hole mounting footprint matches your PCB layout constraints.

Common Mode Chokes Selection Notes

Select this component when a compensated common mode choke with a flat form factor is required. Consider the 1.2A current limit and 200mOhm DC resistance for power loss calculations. Verify thermal performance within the -25°C to 100°C operating range for your specific environment.

Common Mode Chokes Part Context

This part belongs to the DFKF series of compensated chokes from Schurter. It is categorized under common mode chokes and linear chokes. The product is designed for through-hole technology (TH) assembly, distinguishing it from surface mount alternatives in the broader Schurter inductor portfolio.
