DKIH-3237-10D8

Common Mode Chokes Overview

The Schurter DKIH-3237-10D8 is a through-hole common mode choke designed for PCB mounting. It features a radial termination style and an unshielded open design. The component has an inductance of 800 uH with a tolerance of -30% to +50%. It supports a maximum DC current of 10 A and exhibits a typical DC resistance of 10 mOhms. The self-resonant frequency is 2 MHz. Operating temperatures range from -40 C to +100 C. Physical dimensions include a diameter of 37 mm and a height of 26 mm.

Common Mode Chokes Feature Summary

• Current compensated noise suppression for power applications
• Open design for lightweight and compact integration
• Radial leads for direct PCB mounting

Common Mode Chokes Applications

• Single-phase power line filtering
• EMI noise suppression on printed circuit boards
• High current choke applications

Common Mode Chokes Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to ensure correct electrical characteristics and mechanical dimensions. Confirm RoHS compliance status and certification requirements relevant to the target market before finalizing procurement decisions.

Common Mode Chokes Selection Notes

Select this component for single-phase applications requiring high current handling capabilities. Ensure the PCB layout accommodates the radial lead spacing and physical footprint. Verify that the operating temperature range meets the environmental conditions of the intended installation site.

Common Mode Chokes Part Context

This part belongs to the DKIH series of high current chokes from Schurter. The series includes types for both single and three-phase applications, rated from 10 to 50 amperes. These components are specifically engineered to suppress electromagnetic interference generated by power electronics on printed circuit boards.

Common Mode Chokes Replacement Considerations

Consult the official Schurter documentation for verified substitute part numbers within the DKIH series or compatible product lines. Cross-reference inductance, current rating, and physical dimensions to ensure functional equivalence.
