DKIP-0233-5002

$116.52

Description：CMC 50A 2LN TH
Series：DKIP-1
Mfr：SCHURTER Inc.
Package：Bulk

SKU:ce02909cfad4 Category: Common Mode Chokes Brand: SCHURTER Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

DKIP-0233-5002 is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists SCHURTER Inc.. Its product description is CMC 50A 2LN TH. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for DKIP-0233-5002

Description：CMC 50A 2LN TH
Series：DKIP-1
Mfr：SCHURTER Inc.
Package：Bulk
Filter Type：-
Number of Lines：2
Current Rating (Max)：50A
DC Resistance (DCR) (Max)：5mOhm
Voltage Rating - DC：760V
Voltage Rating - AC：540V
Operating Temperature：-25°C ~ 100°C
Ratings：-
Approval Agency：UR
Features：-
Mounting Type：Through Hole
Size / Dimension：4.724" L x 4.724" W (120.00mm x 120.00mm)
Height (Max)：-
Package / Case：Nonstandard
Inductance @ Frequency：-

Common Mode Chokes datasheet and documents for DKIP-0233-5002

DKIP-0233-5002

Common Mode Chokes Overview

The DKIP-0233-5002 is a single-phase compensated high current choke manufactured by SCHURTER Inc. This component functions as a common mode noise suppression filter designed for chassis mounting via wire termination. It features an inductance of 2 mH and supports a maximum DC current rating of 50 A. The device exhibits a maximum DC resistance of 5 milliohms and operates within a temperature range from -25°C to +100°C. With a self-resonant frequency of 300 kHz, it provides effective electromagnetic interference mitigation for high-current applications.

Common Mode Chokes Feature Summary

Compensated design for high-current noise suppression
Single-phase common mode filtering capability
Chassis mount construction with wire terminations

Common Mode Chokes Applications

High-current power supply input filtering
Industrial equipment electromagnetic interference suppression
Power electronics noise reduction

Common Mode Chokes Procurement Notes

Verify the specific part number suffix against official SCHURTER documentation to ensure correct electrical ratings and mechanical configuration. Confirm that the wire termination style matches the system requirements. Check for any recent product change notifications or obsolescence notices directly from the manufacturer before finalizing procurement decisions.

Common Mode Chokes Selection Notes

Select this component when a compensated choke with a 50 A current rating and 2 mH inductance is required. Ensure the chassis mount form factor and wire termination method are compatible with the assembly process. Verify that the operating temperature range meets the environmental conditions of the intended application site.

Common Mode Chokes Part Context

This component belongs to the DKIP series of current compensated chokes from SCHURTER. These devices are engineered for robust noise suppression in demanding electrical environments. The DKIP-0233-5002 specifically addresses high-current single-phase applications requiring efficient common mode attenuation without significant voltage drop.
