DKIP-0329-20D6 is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists SCHURTER Inc.. Its product description is CMC 20A 3LN CHASSIS MOUNT. Review the specifications below when checking this part for your BOM.
Common Mode Chokes specifications for DKIP-0329-20D6
- Description：CMC 20A 3LN CHASSIS MOUNT
- Series：DKIP-3
- Mfr：SCHURTER Inc.
- Package：Bulk
- Filter Type：-
- Number of Lines：3
- Current Rating (Max)：20A
- DC Resistance (DCR) (Max)：5mOhm
- Voltage Rating - DC：760V
- Voltage Rating - AC：540V
- Operating Temperature：-25°C ~ 100°C
- Ratings：-
- Approval Agency：UR
- Features：-
- Mounting Type：Chassis Mount
- Size / Dimension：1.890" L x 1.890" W (48.00mm x 48.00mm)
- Height (Max)：-
- Package / Case：Nonstandard
- Inductance @ Frequency：-
Common Mode Chokes datasheet and documents for DKIP-0329-20D6
Common Mode Chokes Overview
The DKIP-0329-20D6 is a compensated high current choke manufactured by Schurter Inc., designed for three-phase applications. It functions as a common mode choke within the chassis mount inductors category. The component supports rated currents up to 5 A, providing essential noise suppression and signal integrity maintenance in industrial power systems.
Common Mode Chokes Feature Summary
- Compensated design for high current handling
- Three-phase configuration
- Common mode noise suppression
Common Mode Chokes Applications
- Industrial power supply filtering
- Three-phase motor drive protection
- Electromagnetic interference reduction in heavy machinery
Common Mode Chokes Procurement Notes
Verify the specific part number DKIP-0329-20D6 against official Schurter documentation to confirm the three-phase compensated choke specifications. Ensure compatibility with the intended three-phase system voltage and current requirements before procurement.
Common Mode Chokes Selection Notes
Select this component when a compensated high current choke is required for three-phase circuits. Consider the 5 A rated current limit and the need for common mode noise suppression in industrial environments. Verify physical mounting constraints for chassis installation.
Common Mode Chokes Part Context
This component belongs to the chassis mount inductors and coils family from Schurter Inc. It is categorized under common mode chokes, specifically engineered for high current compensation in three-phase electrical systems to mitigate electromagnetic interference.
Common Mode Chokes Replacement Considerations
Cross-reference with other Schurter common mode chokes offering similar 5 A ratings and three-phase configurations. Verify electrical parameters and physical dimensions before substituting.
