DKLL-0331-0430

$48.99

Description：CMC 4A 3LN TH
Series：DKLL-3
Mfr：SCHURTER Inc.
Package：Bulk

SKU:28b922f81543 Category: Common Mode Chokes Brand: SCHURTER Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

DKLL-0331-0430 is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists SCHURTER Inc.. Its product description is CMC 4A 3LN TH. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for DKLL-0331-0430

Description：CMC 4A 3LN TH
Series：DKLL-3
Mfr：SCHURTER Inc.
Package：Bulk
Filter Type：-
Number of Lines：3
Current Rating (Max)：4A
DC Resistance (DCR) (Max)：155mOhm
Voltage Rating - DC：760V
Voltage Rating - AC：540V
Operating Temperature：-25°C ~ 100°C
Ratings：-
Approval Agency：UR
Features：-
Mounting Type：Through Hole
Size / Dimension：3.150" L x 3.150" W (80.00mm x 80.00mm)
Height (Max)：-
Package / Case：Nonstandard
Inductance @ Frequency：-

Common Mode Chokes datasheet and documents for DKLL-0331-0430

DKLL-0331-0430

Common Mode Chokes Overview

The DKLL-0331-0430 is a three-phase common mode choke manufactured by Schurter Inc. It features a compensated design with an inductance of 30 mH and supports a maximum DC current of 4 A. The component has a maximum DC resistance of 155 mOhms and a self-resonant frequency of 75 kHz. It operates within a temperature range of -25°C to +100°C and utilizes wire termination for chassis mounting.

Common Mode Chokes Feature Summary

Three-phase common mode noise suppression
Current compensated choke design
Chassis mount installation style

Common Mode Chokes Applications

Industrial power supply filtering
Motor drive input stages
Three-phase equipment EMI reduction

Common Mode Chokes Procurement Notes

Verify the exact part number suffix, as sources indicate potential confusion between DKLP and DKLL series variants. Confirm availability status, as some listings mark this item as discontinued or restricted. Ensure the datasheet matches the specific electrical requirements before procurement.

Common Mode Chokes Selection Notes

Select this component for applications requiring high inductance in a three-phase configuration. The 4 A current rating and low DC resistance make it suitable for moderate power levels. Verify that the chassis mounting style fits the enclosure design constraints.

Common Mode Chokes Part Context

This component belongs to the DKLP/DKLL series of compensated high inductance chokes from Schurter. These are designed for common mode noise suppression in three-phase systems. The specific model provides balanced performance for industrial environments.
