DKLL-0346-0804

Common Mode Chokes Overview

The DKLL-0346-0804 is a three-line common mode choke manufactured by SCHURTER Inc., designed for through-hole mounting. It supports a maximum DC current of 8A with a DC resistance of 22mOhms. The component operates within a temperature range of -25°C to +100°C and complies with RoHS standards.

Common Mode Chokes Feature Summary

• Provides noise suppression for three-phase power lines
• Supports high current handling up to 8A
• Features through-hole radial termination for PCB integration

Common Mode Chokes Applications

• Three-phase power supply filtering
• Industrial equipment EMI reduction
• Power electronics noise suppression

Common Mode Chokes Procurement Notes

Verify the exact datasheet specifications before integration, as component parameters may vary. Confirm that the through-hole package and 8A current rating align with your circuit design requirements. Ensure compliance with local regulatory standards for electronic components used in your specific application environment.

Common Mode Chokes Selection Notes

Select this component when three-phase noise suppression is required with high current capacity. The through-hole design suits applications needing robust mechanical attachment. Verify that the 22mOhm DC resistance meets your efficiency targets and that the operating temperature range covers your environmental conditions.

Common Mode Chokes Part Context

This part belongs to the DKLL series of current compensated chokes from SCHURTER. It is specifically engineered for common mode interference suppression in multi-phase systems. The product line focuses on reliable performance in industrial and commercial power applications requiring effective electromagnetic compatibility.

Common Mode Chokes Replacement Considerations

No public substitute part numbers are confirmed for this specific model.
