DKLP-0329-0510

$28.15

Description：CMC 5A 3LN TH
Series：DKLP-3
Mfr：SCHURTER Inc.
Package：Bulk

SKU:8c7636caa7a4 Category: Common Mode Chokes Brand: SCHURTER Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

DKLP-0329-0510 is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists SCHURTER Inc.. Its product description is CMC 5A 3LN TH. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for DKLP-0329-0510

Description：CMC 5A 3LN TH
Series：DKLP-3
Mfr：SCHURTER Inc.
Package：Bulk
Filter Type：-
Number of Lines：3
Current Rating (Max)：5A
DC Resistance (DCR) (Max)：48mOhm
Voltage Rating - DC：760V
Voltage Rating - AC：540V
Operating Temperature：-25°C ~ 100°C
Ratings：-
Approval Agency：UR
Features：-
Mounting Type：Through Hole
Size / Dimension：1.890" L x 1.890" W (48.00mm x 48.00mm)
Height (Max)：-
Package / Case：Nonstandard
Inductance @ Frequency：-

Common Mode Chokes datasheet and documents for DKLP-0329-0510

DKLP-0329-0510

Common Mode Chokes Overview

The DKLP-0329-0510 is a compensated high inductance choke manufactured by SCHURTER Inc., designed for three-phase applications. It features a through-hole mounting style and supports a current rating of 5A with a DC resistance of 48mOhm. The component operates within a temperature range of -25°C to 100°C and complies with RoHS3 standards.

Common Mode Chokes Feature Summary

Compensated high inductance design for three-phase systems
Through-hole mounting configuration
RoHS3 compliant construction

Common Mode Chokes Applications

Three-phase power filtering
Industrial equipment EMC suppression
Power supply input stages

Common Mode Chokes Procurement Notes

Verify the exact part number DKLP-0329-0510 against official SCHURTER documentation to confirm specifications. Ensure compatibility with three-phase requirements and through-hole assembly processes. Check for RoHS3 compliance status if required by specific project regulations.

Common Mode Chokes Selection Notes

Select this component for three-phase circuits requiring compensated high inductance chokes. Consider the 5A current rating and 48mOhm DC resistance when designing power filters. Verify that the through-hole package fits the target PCB layout and that the operating temperature range meets environmental conditions.

Common Mode Chokes Part Context

This component belongs to SCHURTER's line of common mode chokes and inductors. It is specifically engineered for noise suppression in three-phase electrical systems, providing reliable performance in industrial and commercial power applications.
