DKLP-0333-1610

Common Mode Chokes Overview

The DKLP-0333-1610 is a three-phase common mode choke from the SCHURTER DKLP series, designed for current compensated noise suppression. It features a through-hole mounting style with wire termination. The component provides an inductance of 2 mH and supports a maximum DC current of 16 A. Its maximum DC resistance is specified at 30 mOhms, with a self-resonant frequency of 250 kHz. The unit operates within a temperature range of -25°C to +100°C.

Common Mode Chokes Feature Summary

• Three-phase configuration for balanced noise suppression
• Current compensated design for high inductance stability
• Through-hole construction for robust chassis or panel integration

Common Mode Chokes Applications

• Industrial power supply filtering
• Three-phase motor drive noise reduction
• Electromagnetic interference suppression in AC/DC converters

Common Mode Chokes Procurement Notes

Verify the specific suffix against the official Schurter datasheet to confirm terminal type and lead length. Ensure the selected variant matches the required current rating and inductance tolerance for the target circuit. Cross-reference the manufacturer part number with authorized distributor catalogs to confirm availability and origin. Check for any recent product change notifications that may affect pinout or mechanical dimensions before finalizing procurement orders.

Common Mode Chokes Selection Notes

Select this component when three-phase common mode noise attenuation is required in compact spaces. The 16 A current rating suits medium-power industrial applications. Verify that the 2 mH inductance meets the filter cutoff requirements. Ensure the through-hole package fits the PCB layout constraints. Compare thermal performance against ambient operating conditions to ensure reliability within the specified temperature range.

Common Mode Chokes Part Context

This component belongs to the DKLP series of compensated chokes by Schurter. These devices are engineered for high-performance electromagnetic compatibility in power electronics. The series emphasizes low impedance at differential modes while maintaining high common mode impedance. This specific model targets three-phase systems where balanced noise cancellation is critical for regulatory compliance.

Common Mode Chokes Replacement Considerations

Consult the official Schurter replacement guide for direct equivalents. Verify that substitute parts match the 16 A current rating and 2 mH inductance. Ensure mechanical footprint compatibility for through-hole mounting. Confirm that alternative components meet the same thermal and electrical specifications for three-phase applications.
