DLP0NSC900HL2L

Description：CMC 75MA 90 OHM SMD
Series：*
Mfr：Murata Electronics
Package：Tape & Reel (TR)

SKU:0f9e1e2ba547 Category: Common Mode Chokes Brand: Murata Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

DLP0NSC900HL2L is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists Murata Electronics. Its product description is CMC 75MA 90 OHM SMD. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for DLP0NSC900HL2L

Description：CMC 75MA 90 OHM SMD
Series：*
Mfr：Murata Electronics
Package：Tape & Reel (TR)
Filter Type：-
Number of Lines：-
Current Rating (Max)：-
DC Resistance (DCR) (Max)：-
Voltage Rating - DC：-
Voltage Rating - AC：-
Operating Temperature：-
Ratings：-
Approval Agency：-
Features：-
Mounting Type：-
Size / Dimension：-
Height (Max)：-
Package / Case：-
Inductance @ Frequency：-
Impedance @ Frequency：-
Qualification：-
Grade：-

Common Mode Chokes datasheet and documents for DLP0NSC900HL2L

DLP0NSC900HL2L

Common Mode Chokes Overview

The Murata DLP0NSC900HL2L is a surface-mount common mode choke belonging to the DLP0NS series. It features a 90 Ohm impedance at 100 MHz and supports a maximum DC current of 75 mA. The component has a maximum DC resistance of 4 Ohms and operates within a temperature range of -40°C to +85°C. Its physical dimensions are 0.85 mm in length, 0.65 mm in width, and 0.45 mm in height, corresponding to the 03025 (0807 metric) package.

Common Mode Chokes Feature Summary

Provides common mode noise suppression for high-frequency interference
Utilizes an unshielded film-type construction for compact integration
Designed for surface-mount PCB assembly with SMD/SMT termination

Common Mode Chokes Applications

High-speed data line filtering
Portable electronic device signal integrity protection
Compact circuit board noise reduction

Common Mode Chokes Procurement Notes

This component is officially discontinued and no longer manufactured by Murata Electronics. Verification of availability should focus on surplus distributors or secondary markets rather than direct manufacturer channels. Buyers must confirm the authenticity and storage history of existing stock due to the end-of-life status. Replacement strategies should prioritize the suggested alternate part numbers provided in official documentation to ensure compatibility.

Common Mode Chokes Selection Notes

Engineers selecting this component should note its discontinuation status and evaluate alternative solutions for new designs. The small 03025 footprint requires precise placement considerations during assembly. Designers must verify that the 75 mA current rating and 4 Ohm DC resistance meet the specific circuit requirements before implementation. Cross-referencing with active series components is recommended to maintain supply chain stability.

Common Mode Chokes Part Context

The DLP0NSC900HL2L belongs to Murata's DLP0NS series of miniature common mode chokes. This series is characterized by ultra-small footprints suitable for space-constrained applications. The component utilizes film technology to achieve performance in a minimal volume. It represents a specialized solution for filtering applications where size constraints are critical.
