DQS1-12-S12-S

DQS1-12-S12-S is listed in the DC DC Converters range at ChipApex. The manufacturer field lists CUI Inc.. Its product description is DC-DC ISOLATED, 1W, 10.8~13.2 VD. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for DQS1-12-S12-S

• Description：DC-DC ISOLATED, 1W, 10.8~13.2 VD
• Series：DQS1-S (1W)
• Mfr：CUI Inc.
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：10.8V
• Voltage - Input (Max)：13.2V
• Voltage - Output 1：12V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：84mA
• Power (Watts)：1 W
• Voltage - Isolation：1 kV
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 95°C (With Derating)
• Efficiency：80%
• Mounting Type：Through Hole
• Package / Case：4-SIP Module
• Size / Dimension：0.46" L x 0.24" W x 0.40" H (11.6mm x 6.0mm x 10.2mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：cURus
• Standard Number：62368-1
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for DQS1-12-S12-S
