Product Detailed Parameters
- Description：60 V 1000/2000 MA 3-PHASE GATE D
- Series：-
- Mfr：Texas Instruments
- Package：Tape & Reel (TR),Cut Tape (CT)
- Motor Type - Stepper：Multiphase
- Motor Type - AC, DC：Brushless DC (BLDC)
- Function：Driver - Fully Integrated, Control and Power Stage
- Output Configuration：Pre-Driver - Half Bridge (3)
- Interface：-
- Technology：Power MOSFET
- Step Resolution：-
- Applications：General Purpose
- Current - Output：-
- Voltage - Supply：4.5V ~ 60V
- Voltage - Load：-
- Operating Temperature：-40°C ~ 125°C (TA)
- Mounting Type：Surface Mount
- Package / Case：28-VFQFN Exposed Pad
- Supplier Device Package：28-WQFN (4x4)
- Grade：-
- Qualification：-
Download product information
Overview
The DRV8328ARUYR is a three-phase brushless DC (BLDC) gate driver manufactured by Texas Instruments. It operates within a supply voltage range of 4.5 V to 60 V and integrates high-side and low-side drivers for BLDC motor applications. The device features an integrated bootstrap diode, programmable dead-time control, and overcurrent protection with adjustable thresholds. It supports PWM inputs for commutation control and includes diagnostic outputs for fault indication.
Feature Summary
- Integrates high-side and low-side drivers with an internal bootstrap diode for efficient power stage driving
- Provides programmable dead-time control to prevent shoot-through in the motor drive bridge
- Includes overcurrent protection with adjustable threshold settings for robust system safety
Applications
- Three-phase BLDC motor drives
- Industrial automation systems
- Home appliance motor control
Procurement Notes
Verify the specific suffix ARUYR against the manufacturer datasheet to confirm package type and tape-and-reel configuration. Ensure compatibility with the target PCB footprint and soldering profile. Confirm that the component meets all required environmental and regulatory standards for the intended deployment region.
Selection Notes
Select this component when designing three-phase BLDC motor control circuits requiring a 60 V maximum supply voltage. Consider its integrated bootstrap diode and programmable dead-time features for simplified design. Evaluate the overcurrent protection thresholds against the motor's peak current requirements to ensure adequate system protection.
Part Context
The DRV8328 belongs to Texas Instruments' family of three-phase BLDC gate drivers. It is designed to interface directly with microcontrollers or sensorless control algorithms. The device simplifies the design of motor drive stages by integrating necessary logic and protection functions into a single compact package.
Replacement Considerations
The DRV8329 is a documented pin-compatible upgrade offering enhanced performance characteristics. Verify electrical specifications and thermal requirements before substituting either part.
