DRV8428PWPR

$2.68

Description：35V, 1A BIPOLAR STEPPER MOTOR DR
Series：-
Mfr：Texas Instruments
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:4880d10240cd Category: Motor Drivers, Controllers Brand: Texas Instruments

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：35V, 1A BIPOLAR STEPPER MOTOR DR
Series：-
Mfr：Texas Instruments
Package：Tape & Reel (TR),Cut Tape (CT)
Motor Type - Stepper：Bipolar
Motor Type - AC, DC：Brushless DC (BLDC), Brushed DC
Function：Driver - Fully Integrated, Control and Power Stage
Output Configuration：Half Bridge (2)
Interface：Step/Direction
Technology：Power MOSFET
Step Resolution：>256 Microsteps
Applications：General Purpose
Current - Output：1A
Voltage - Supply：4.2V ~ 33V
Voltage - Load：-
Operating Temperature：-40°C ~ 125°C (TA)
Mounting Type：Surface Mount
Package / Case：16-PowerTSSOP (0.173", 4.40mm Width)
Supplier Device Package：16-HTSSOP
Grade：-
Qualification：-

Download product information

DRV8428PWPR

Overview

The DRV8428PWPR is a fully integrated bipolar stepper motor driver manufactured by Texas Instruments. It supports a supply voltage range of 4.2V to 33V and delivers an output current of 1A. The device features a step/dir interface and offers microstepping resolution up to 1/256. It utilizes Power MOSFET technology and is housed in a 16-HTSSOP package with a width of 4.40mm. The operational temperature range spans from -40°C to 125°C.

Feature Summary

Integrates control logic and power stage for bipolar stepper motors
Supports high-resolution microstepping up to 1/256
Includes integrated current sensing capabilities
Operates via standard step and direction interface

Applications

Bipolar stepper motor control systems
General purpose motion control applications
Industrial automation equipment
Medical devices requiring precise positioning

Procurement Notes

Verify the specific ordering suffix matches the required tape and reel configuration, as variations exist between cut tape, reel, and Digi-Reel formats. Confirm the package type corresponds to the 16-HTSSOP specification. Ensure the component status is listed as active or recommended for new designs. Cross-reference the manufacturer part number against official distributor catalogs to validate authenticity and avoid counterfeit components.

Selection Notes

Select this component when a compact solution for bipolar stepper motors is required. It is suitable for applications needing microstepping precision and integrated current sensing. Consider the 16-HTSSOP package constraints for PCB layout. Evaluate thermal performance requirements given the 125°C junction temperature rating. Compare against other drivers if higher current capacity or different interface protocols are necessary.

Part Context

This part belongs to the DRV8428 family of motor drivers from Texas Instruments. It is designed for low-power stepper motor applications. The PWPR suffix indicates the specific packaging and shipping format. Related evaluation modules include the DRV8428PEVM and DRV8428EVM for development purposes. The device complements other TI motor control solutions like the DRV8847.
